Definitions and Warnings
The necessary ESD protective measures are clearly shown in the following
diagram:
♦ a = Conductive floor surface
♦ b = ESD table
♦ c = ESD shoes
♦ d = ESD overall
♦ e = ESD chain
♦ f = Cubicle ground connection
Fig. 0-1 ESD protective measures
0-4
All manuals and user guides at all-guides.com
08.2000
d
b
e
f
c
a
Sitting
d
f f f
c
a
Standing
6SE7087-6NX84-0FJ0
Operating Instructions SIMOVERT MASTERDRIVES
SLB - SIMOLINK Board
b
d
e
f
c
a
Standing / Sitting
