SLB - SIMOLINK Board
4

Connecting-up

The SLB optional board is provided with
♦ two connections for SIMOLINK and
♦ one connection for the external voltage supply
4.1

Connecting SIMOLINK

Connecting Two connections for the fiber-optic cables are available for SIMOLINK, one
input and one output respectively.
SIMOLINK
You must always connect SIMOLINK up to both connections.
CAUTION
!
Siemens AG 6SE7087-6NX84-0FJ0
SIMOVERT MASTERDRIVES
All manuals and user guides at all-guides.com
08.2000
If you confuse the two connections for signal input and signal output,
SIMOLINK cannot operate.
Operating Instructions
Connecting-up
4-1
