• Do not transport or tip the shredder with the motor
running.
• Keep hands, other body parts and clothing out of
the filling chamber and ejection channel and away
from other moving parts.
• In the event of blockages in the machine intake or
ejection, switch off the motor and disconnect the
machine from the mains before removing leftover
material in the intake opening or ejection channel.
Ensure that the motor is free of rubbish and other
accumulations in order to safeguard the motor from
damage or possible fire. Remember that the cutting
tool is also activated when the starting mechanism
is started on a motor operated machine.
CAUTION! The following states how damage to the
trimmer and possible injury to people can be avoided:
• Clean the ventilation slits regularly; keep to the
maintenance instructions.
• Do not overload your device. Work only within the
indicated range of performance. Do not employ any
low power machines for heavy work. Do not use
your device for purposes for which it has not been
designed.
• Only switch the shredder off once the funnel feeder
is completely empty since the shredder may oth-
erwise clog up and not be able to start afterwards.
• Do not attempt to repair the shredder yourself un-
less you are qualified to do so. Any work not speci-
fied in this manual may only be carried out by our
service centre.
Electrical safety
m CAUTION! The following states how to avoid acci-
dents and injuries due to electric shock:
• Use the tension relief provided for the fixing of the
extension cord.
• Damaged cables, coupling and plugs or connecting
leads not corresponding to specifications, must not
be employed. Remove the plug immediately from
the plug socket in case of damage to the mains
cable. Do not touch the mains power supply cable
under any circumstances until you have pulled the
plug out of the mains socket.
• If the power cable for this equipment is damaged, it
must be replaced by the manufacturer, a customer
service agent of the same or a similarly qualified
person in order to prevent hazards.
• Do not use the appliance if the on/off switch does
not work properly. Always have a damaged switch
repaired by our Service Centre.
• Only use extension cables that have been approved
for outdoor use and are resistant to splash water.
The core diameter for extension cables measuring
up to 25 m must be at least 2.5 mm², and 2.5 mm²
for cables longer than 25m. Always roll the whole
cable off the reel before use. Check the cable for
damage.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
• Do not unplug the shredder by the cable. Keep the
cable away from heat, oil and sharp edges.
m WARNING! This electric tool generates an elec-
tromagnetic field during operation. This field can im-
pair active or passive medical implants under certain
conditions. In order to prevent the risk of serious or
deadly injuries, we recommend that persons with
medical implants consult with their physician and the
manufacturer of the medical implant prior to operat-
ing the electric tool.

6. Technical data

Dimensions LxWxH (mm)
Blade cylinder Ø (mm)
Number of blades
Collection box capacity (l)
Transport wheels Ø (mm)
Weight kg
Motor V/Hz
Nominal consumption P1 (W)
Revolutions max. (per min)
Blade cylinder revolutions
max. (per min)
Operating type
Subject to technical changes!
Noise levels
Guaranteed sound power level L
Measured sound power level L
Sound pressure level L
pA
Measurement uncertainty K
Note: The specified sound levels have been deter-
mined using a standardised test procedure and can
be used to compare different electronic devices. Fur-
thermore, these values can be used to assess in ad-
vance the strain on the user caused by the sound.
m WARNING! Depending on how you use the pow-
er tool, the actual values can vary from those stated.
Take measures to protect yourself from noise. Con-
sider the entire work process, i.e. even times during
which the power tool works without load or is switched
off. Suitable measures include, amongst others, regu-
lar maintenance and care of the power tool and the
attachments, regular breaks as well as good planning
of the work processes.
585 x 480 x 910
88
8
55
190
27,6
230-240V~ 50Hz
2200
2850
46
S6 40%
96 dB(A)
WA
93,1 db(A)
WA
73,1 dB(A)
2,67 dB(A)
