English VWU 65 - VWU 80

3.2 Installation instructions for valve and actuator

OK
OK
OK
Fig. 6:•Permissible mounting positions
ATTENTION!
Supplementary notes:
All components must be installed in a dry and frost-free location.
ATTENTION!
Before start-up, always ensure that the operating switch is in position 4
(see Fig. 7:•).
Undesired changes to the heat pump's operating state may result if this
is not observed.
4 = Automatic
Fig. 7:•Notes on the actuator operating switch
EN-6 452163.66.30 · FD 9801
