circumstances, may impair the
functionality of active or passive
medical implants. To reduce the risk
of serious or lethal injuries, we rec-
ommend that persons with medical
implants consult their doctor and
the manufacturer of their medical
implant before operating the ma-
chine.
Observe the safety information and
notes on charging and proper use
as shown in the instruction manual
for your battery and charger from
the Parkside X 20 V Team series. A
detailed description of the charging
process and further information can
be found in the separate operating
instructions.

Assembly

Always wear protective
gloves when working with
the chainsaw and employ
only original parts. Pull out
the power plug before doing
any work on the chainsaw
itself – injury hazard!
Before putting the electric chain saw into
operation, you must:
-
adjust the saw chain tension,
-
pour in chain oil,
-
Charge and insert the battery
-
check the function of the chain brake
and the automatic oil pump.
Mounting the saw chain
and blade
Switch off the device and remove
the battery before carrying out any
maintenance work.
1. Lay the saw on a flat surface.
2. Turn the fastening bolt (10) anti-
clockwise (
sprocket chain wheel covering (12).
3. Spread the chain (7) out into a loop
with the cutting edges running clock-
wise . Use the graphical symbol on
the blade or below the chain sprocket
(20) as a guide to align the saw chain
(7).
4. Slide the saw chain (7) into the bar
guide groove. To mount the guide
bar, raise it to an angle of approx.
45 degrees. This will make it easier
to replace the saw chain (7) onto the
sprocket (20).
5. Place the chain bar (8) and saw chain
(7) on the bar bolts (19). When the pin
(19a) to the right of the coach screw
(19) sits in the slotted recess on the
blade, the blade is placed correctly.
It is normal that the saw chain (7) is
slack.
6. Position the sprocket chain wheel cover-
ing (12). The chain tensioner pin (21)
on the inside of the sprocket cover (12)
must be guided into the chain tension
pin holder (22).
7. Pre-tension the saw chain (7) by turning
the screw for the chain quick-tensioning
system (11) in clockwise direction.
8. Tighten the fastening bolt (10) (
Note that the saw can re-oil.
Please note that the saw re-oils after use
and oil may leak out if it is stored on its
side or on the head. This is a normal
process due to the necessary ventilation
opening on the upper edge of the tank and
GB
) to remove the
Direction of travel of the
saw chain
IE
).
43
