VDC-295AIOD / VDC-535AIOD
2.7 Connectors
Connect the video output (BNC) connector to the monitor or the video input.
Connector 1: AC+ / AC- / G / R- / R+ /G
Colour Description
Red AC+: 24 V AC
Orange AC-: 24V AC
Yellow G: GND
Green R- (RS-485)
Grey R+ (RS-485)
Blue G: GND
Connector 2: F+ / F-
Colour Description
Black F+: 24 V AC (heater and fan)
Brown F-: 24 V AC (heater and fan)
Connector 3: AL1 / AL2 / AL3 / AL4 / G
Colour Description
Grey AL1: Alarm input 1
Blue AL2: Alarm input 2
Green AL3: Alarm input 3
Yellow AL4: Alarm input 4
Orange G: GND
Connector 4: COM / NC / NO
Colour Description
Red COM: Common
Brown NC: Alarm output
Black NO: Alarm output
Subject to technical changes. Errors excepted.
