3. Start up

3.1 Lifting and carrying

For transport with a forklift truck, use the rigging holes in the frame. The compressor has
slotted rigging holes with width C – fig. 3.1. Move the compressor carefully.
Fig. 3.1.1 Lifting and carrying A07.. – A22..
Model
А07..
А11..
А15..
А18..
А22..
16
All lifting should be carried out using a forklift truck with a carrying
capacity suited to the compressor. Lifting may be carried out with
loading cranes, winches and other machinery, using a crossbeam
with the right length. Local safety guidelines for lifting have to be
observed.
G
A, mm B, mm
100
130
383
135
B
A
C
C, mm D, mm
92
202
185
302
D
G, mm
900
1000
