Power Connector - LX Navigation 6000 1.0 Bedienungsanleitung

Power Connector(1):

SD15 BU
8
15
7
14
6
13
5
12
4
11
3
10
2
9
1
LX6000/LX600
BINDER 5P
711-2-99-0096-00-05
1
3
5
50cm
30cm
20cm
20cm
50cm
PC CABLE
PC
SD9 F
1.5m
2
3
5
12V POWER SUPPLY
red +12V
black MASSE
LCD Backlight ON/OFF
red
red
+12V/RS485
SD9 F
yellow A 1
red +12V 6
white +12V 7
black B 4
9
shield GND 5
RS232C
SD9 M
white RXD 2
black TXD 3
shield GND 5
PC-RS232C
BINDER 5P
09-0097-00-05
white RXD 1
black TXD 3
shield GND 5
LX6000/Colibri CABLE
LX6000
SD9 F
2
3
5
Colibri
SD9 F
3m
2
3
5
