Maintenance and servicing

8. Maintenance and servicing
8.1 Important care work
8.2 Replacing pre-filters
If a pre-filter is dirty, it must be replaced. To do so, please follow these steps:
ersa X-TOOL VARIO
All manuals and user guides at all-guides.com
Caution! Material damage is possible!
Only use Ersa original spare parts and consumables to ensure safe opera-
tion and warranty coverage.
• Make sure that the desoldering tip is always tin-plated.
• Wipe the desoldering tip, if necessary, before desoldering to remove
flux material and solder residues with the dry cleaner or a damp
sponge.
• Tin-plate the tip again before desoldering; this improves heat transfer
and reduces desoldering time.
• Now and then clean the soldering duct using the included tip cleaner.
This tool can loosen and remove flux material and solder residues.
• Change the filter in good time.
• Now and then use a new silicone holder, making sure it is made of
high quality silicone. Due to temperature load, materials age and
sealability is reduced.
• Make sure that ventilation openings do not become ineffective due to
dust deposits.
■
Remove the X-TOOL VARIO from the pre-filter.
■
Remove the pre-filter from the vacuum connection of the control
station.
■
Insert a new pre-filter.
■
Re-install the X-VARIO TOOL hose on the pre-filter.
