Error treatment

7. Error treatment
The Error treatment chapter should help you to identify and rectify simple problems with
the tool. Should you not be able to solve a problem, please contact the Ersa service.
Errors
Insufficient desoldering; residual
solder is not completely absorbed.
Vacuum pump frequent starting.
Vacuum pump does not start.
Desoldering tip does not get hot.
Actual value display indicates too
low a temperature although the
desoldering tip is hot.
Actual value display indicates a
high temperature, although the
desoldering tip is not heated.
22
All manuals and user guides at all-guides.com
3BA00215 • 2016-07-11 • Rev. 3
Cause
Desoldering tip is clogged.
Desoldering tip is not wetted.
Residual solder pot and/or filter
are full.
Leakage in the vacuum system.
Leakage in the vacuum system.
Desoldering iron is not/not prop-
erly plugged in.
Control station voltage supply or
fuse are defective.
Control station is not connected
to the mains supply.
Control station is not switched on.
Tool is not/not properly connect-
ed to the control station.
Control station voltage supply or
fuse are defective.
Heating element of the desolder-
ing iron is defective (error mes-
sage "ERR8" is displayed on the
control station).
Thermal sensor of the desoldering
iron is defective.
Thermal sensor of the desoldering
iron is broken (error message
"ERR7" is displayed on the control
station).
Rectification
Clean the soldering tip with the
included tip cleaner, or replace the
desoldering tip.
Reactivate the tip with a suitable
tip activator or replace it.
Clean the residual solder pot and
replace the filter.
Check the sealing plug, connectors
and hoses for proper fitting.
Check the sealing plug, connectors
and hoses for proper fitting.
Check whether the tool is properly
connected to the control station.
Check the control station voltage
supply and fuse (observe the op-
erating instructions of the control
station).
Check for any error messages on the
display of the control station.
Connect the control station to the
mains supply.
Switch on the control station.
Switch on the control station.
Check whether the desoldering
iron is properly connected to the
control station.
Check the control station voltage
supply and fuse (observe the op-
erating instructions of the control
station).
Check for any error messages on the
display of the control station.
Replace heating head or send the
tool to the Ersa service.
Replace heating head or send the
tool to the Ersa service.
Replace heating head or send the
tool to the Ersa service.
