Installation Procedures
2. Floor Type Installation
When the unit is being installed on the floor,
refer to the following instructions:
Floor
3. Installation on the ceiling
A
Model
40VC009~018F-7S-QEE
40VC024~054F-7S-QEE

Ceiling Installation

(1) Use Ø10 hanger bolts, prepared on the site. Please refer to figure on the right during installation.
When the unit is installed in the ceiling,side B is to be lower than side A, for condensate discharge (as shown below).
A
Connecting
pipe
Drain pipe
Ceiling
a
Over30 cm Over30 cm
Over80 cm Over150 cm
10-15mm
B
CAUTION : drain pipe leading-out direction shown with figure below.
Correct
Attention to distance from the unit to household appliances or
obstacles (as shown in the figure)
Over 30 cm
B
b c
Over2 cm
Over10 cm
A
9
Drain pipe
Wrong
Over 30 cm
B
Wrong
C
10-15mm
