Connecting-up
PELV power
supply
-F1
DC
24 V
-F2
7-10
-X9
2 1
-X100
33
Control
electronics
34
-X100
33
Control
electronics
34
-X100
33
Control
electronics
34
-X100
33
Control
electronics
34
-X100
33
Control
electronics
34
Fig. 7-4 Sectional drive with rectifier unit and inverters
3AC
380 - 480 V
-K1
U1 V1 W1
Rectifier unit
Inverter 1.1
Inverter 1.2
Inverter 1.3
Inverter 2.1
6SE7087-6KP50
