Install optional modules, if any

See chapter Electrical installation in ACS580-01 (0.75 to 250 kW, 1.0 to 350 hp)
hardware manual (3AXD50000044794 [English]).

Reinstall cover

See figure H on page 438.
1. IP21, Reinstall the box cover: Slide the cover upwards (1a) and tighten the
retaining screws (1b).
2. IP21, Reinstall the module cover: Put the tabs on the inside of the cover top in
their counterparts on the housing (2a), press the cover at the bottom (2b) and
tighten the retaining screws (2c).
3. IP55, Reinstall the front cover: Put the tabs on the inside of the cover top in their
counterparts on the housing (3a), press the cover at the bottom (3a) and tighten
the retaining screws (3b).
For start-up instructions, see chapter
EN – R5 Quick installation guide 183
EN – Quick start-up guide on page 317.
