Operating Mode - Sentiotec Infrabox basic S Bedienungsanleitung

Installation instructions, only for experts

6.1. Operating mode

DIP-Bank 1
Function selection switch 1 and 2
In the operating mode the following
settings are possible:
Function selec-
tion switch
Normal
Timer I/0
Seat (optional)
Normal: Switchable or dimmable infrared heater/infrared plate.
The dimming function of the infrared heater/infrared plate is activated via the infra-
controller, see 6.2. Operating type (infrared heater/infrared plate) on page 20.
Timer I/0 (On/Off): in the On/Off operating mode, the controller switches off after
the set On-time has elapsed and is not activated again.
Switchable infrared heater / infrared plate.
For additional settings, see 6.6. On-time (I/0 timer) on page 24 and
Fig. 16: Timer I/0 operating mode on page 25.
Seat (Function is only available in combination with the optional seat sensor)
For additional settings, see 6.5. Seat time (optional for seat sensor) on page 23.
1 2
OFF OFF
ON OFF
ON ON
Fig. 9: Operating mode
p. 19/32
ON
OFF
EN
