14 IIoT-Funktionalität
Name Datentyp
outputState boolean
forced boolean
simulated boolean
actuatorDiag boolean
sensorDiag boolean
maxOutputCurrent number
_mA
current_mA number
voltage_mV number
PORT Object
port_type string
iolink_mode number
iolink_text string
aux_mode number
aux_text string
cq_mode number
Handbuch EtherNet/IP
Version 1.2 05/2021
Beschreibung
Output data bit to the physical output
pin
True, if the output pin of this channel is
forced
True, if the input value to the PLC of
this channel is simulated
True, if the output is in short circuit /
overload condition
True, if the sensor supply (Pin 1) is in
short circuit / overload condition
Maximum output current of the output
in mA
Measured current of the output in mA
(if current measurement is available)
Measured voltage of this output in mV
(if voltage measurement is available)
Textual representation of the IO-Link
port type
Current port mode:
0 = Inactive
1 = Digital output
2= Digital input
3 = SIO
4 = IO-Link
Textual representation of the current
port mode
Indicates the configured mode for the
Pin 2:
0 = No AUX
1 = AUX output (always on)
2 = Digital output (can be controlled by
cyclic data)
3 = Digital input
Textual representation of the current
aux mode
Port mode according to IOL
specification
14.3 REST API
Beispiel
"Digital Input"
"AUX Output"
