Specifications

Specifications Chart

Item
Engine Intek™ Briggs & Stratton
Displacement 656 cc
Electrical System 9-Amp
Battery 12V - 195CCA
Oil Capacity 64 oz (1,9 L)
Spark Plug Gap .030 in (,76 mm)
Spark Plug Torque 180 lb-in (20 Nm)
Fuel Tank Capacity 13.2 L
Transmission
Make and Type
Tuff Torq
Chassis
Front Wheel Size 15 x 6-6
Front Wheel Inflation 12 - 14 psi (0,82 - 0,92 Bar)
Pressure
Rear Wheel Size 20 x 8-8
Rear Wheel Inflation 10 psi (0,68 Bar)
Pressure
Item
Engine Intek™ Briggs & Stratton
Displacement 656 cc
Electrical System 9-Amp
Battery 12V - 195CCA
Oil Capacity 64 oz (1,9 L)
Spark Plug Gap .030 in (,76 mm)
Spark Plug Torque 180 lb-in (20 Nm)
Fuel Tank Capacity 11 L
Transmission
Make and Type
Tuff Torq
Chassis
Front Wheel Size 15 x 6-6
Front Wheel Inflation 12 - 14 psi (0,82 - 0,92 Bar)
Pressure
Rear Wheel Size 22 x 10-8
Rear Wheel Inflation 10 psi (0,68 Bar)
Pressure

Power Ratings Disclaimer

Power Ratings: The gross power rating for individual
gasoline engine models is labeled in accordance with
SAE (Society of Automotive Engineers) code J1940 Small
Engine Power & Torque Rating Procedure, and is rated in
accordance with SAE J1995. Torque values are derived at
2600 RPM for those engines with "rpm" called out on the
label and 3060 RPM for all others; horsepower values are
derived at 3600 RPM. The gross power curves can be viewed
at www.BRIGGSandSTRATTON.COM. Net power values are
taken with exhaust and air cleaner installed whereas gross
2691481, 2691487,
2691683 2691488, 2691576
Intek™ Briggs & Stratton
656 cc
9-Amp
12V - 195CCA
64 oz (1,9 L)
.030 in (,76 mm)
180 lb-in (20 Nm)
13.2 L
®
K46 Tuff Torq
15 x 6-6
12 - 14 psi (0,82 - 0,92 Bar)
22 x 10-8
10 psi (0,68 Bar)
2691701, 2691715 2691684, 2691702
Professional Series™ Briggs
& Stratton
725 cc
9-Amp
12V - 230CCA
64 oz (1,9 L)
.030 in (,76 mm)
180 lb-in (20 Nm)
11 L
®
K46 Tuff Torq
15 x 6-6
12 - 14 psi (0,82 - 0,92 Bar)
22 x 9.5-12
10 psi (0,68 Bar)
2691482, 2691483, 2691489
Professional Series™ Briggs
& Stratton
725 cc
9-Amp
12V - 230CCA
64 oz (1,9L)
.030 in (,76 mm)
180 lb-in (20 Nm)
13.2 L
® ®
K46 Tuff Torq
15 x 6-6
12 - 14 psi (0,82 - 0,92 Bar)
22 x 9.5-12
10 psi (0,68 Bar)
2691685, 2691703
Professional Series™ Briggs
& Stratton
725 cc
9-Amp
12V - 230CCA
64 oz (1,9 L)
.030 in (,76 mm)
180 lb-in (20 Nm)
11 L
® ®
K46 Tuff Torq
15 x 6-6
12 - 14 psi (0,82 - 0,92 Bar)
22 x 9.5-12
10 psi (0,68 Bar)
power values are collected without these attachments. Actual
gross engine power will be higher than net engine power
and is affected by, among other things, ambient operating
conditions and engine-to-engine variability. Given the wide
array of products on which engines are placed, the gasoline
engine may not develop the rated gross power when used in
a given piece of power equipment. This difference is due to
a variety of factors including, but not limited to, the variety of
engine components (air cleaner, exhaust, charging, cooling,
carburetor, fuel pump, etc.), application limitations, ambient
operating conditions (temperature, humidity, altitude), and
2691714
Intek™ Briggs & Stratton
656 cc
9-Amp
12V - 195CCA
64 oz (1,9L)
.030 in (,76 mm)
180 lb-in (20 Nm)
11 L
®
K46 Tuff Torq K46
15 x 6-6
12 - 14 psi (0,82 - 0,92 Bar)
20 x 8-8
10 psi (0,68 Bar)
2691700
Intek™ Briggs & Stratton
656 cc
9-Amp
12V - 195CCA
64 oz (1,9 L)
.030 in (,76 mm)
180 lb-in (20 Nm)
11 L
®
K46 Tuff Torq K46
15 x 6-6
12 - 14 psi (0,82 - 0,92 Bar)
20 x 10-8
10 psi (0,68 Bar)
19
