A dead battery or one too weak to start the engine can
be the result of a defect in the charging system or other
electrical component. If there are doubts about the cause of
the problem, see an Authorized Service Dealer. To replace
the battery, see Clean the Battery and Cables.

Mower Blade Stop Time

WARNING
If the mower blade does not STOP in 5 seconds or less, the
clutch must be adjusted. DO NOT operate the machine
until the adjustment has been corrected by a Briggs &
Stratton Authorized Service Dealer.
After the Power Take-Off (PTO) switch turns OFF, the mower
blades and mower drive belt must STOP in 5 seconds or
less. If the mower drive belt does not STOP in 5 seconds,
contact Briggs & Stratton Authorized Service Dealer for
repairs.

Change the Engine Oil

1. Put the rider on a level surface (A, Figure 11).
2. Stop the engine and remove starter insert or key (B).
3. Clean the oil fill and filter areas.
4. Remove the dipstick (C).
5. Disconnect the oil drain hose (A, Figure 12)
6. Carefully remove the cap (B), and lower the hose into an
approved container (C).
7. After the oil has drained, install the cap tightly, then attach
the hose to the side of the engine.
8. Remove the oil filter (B, Figure 13) and discard.
9. Lightly lubricate the oil filter gasket (A) with clean oil.
10. Install the oil filter by hand until the gasket touches the
oil filter adapter (C). Then, tighten the oil filter 1/2 to 3/4
turns.
11. Add oil. Refer to the Check and Add Oil section.
Air Filter Assembly (Cartridge with pre-
cleaner)
WARNING
DO NOT start or operate the engine without an air cleaner
assembly or air filter as it is a fire hazard.
NOTICE DO NOT use pressurized air or solvents to clean
the air filter. Pressurized air can damage the filter and
solvents will dissolve it.
1. Loosen the fasteners (A, Figure 14) and remove the
cover (B).
2. Remove the air cleaner assembly (C) and disassemble it.
3. Remove unwanted material or debris that can get into the
carburetor throat (D).
4. Remove the pre-cleaner from the air filter.
16
5. Lightly tap the air filter on a hard surface to loosen debris.
If the air filter is dirty, replace it.
6. Soak the pre-cleaner in liquid detergent and water. Let it
fully air dry. DO NOT lubricate the pre-cleaner.
7. Assemble the dry pre-cleaner to the air filter.
8. Install the air filter assembly.
9. Install the cover and tighten the fasteners.

Push the Tractor By Hand

1. Disengage the Power-Take-Off (PTO) (E, Figure 3).
2. STOP the engine. See Stop the Engine.
3. Pull the transmission release lever (S, Figure 15). Then,
push the lever down to lock in position.
4. The rider can be pushed by hand.
WARNING
Towing the unit will cause transmission damage. Do not use
another vehicle to push or pull this unit. Do not actuate the
transmission release lever while the engine is ON.

Check the Spark Plugs

WARNING
Unintentional sparking can result in fire or electric shock.
Unintentional start-up can result in entanglement, traumatic
amputation, or laceration.
When you test for spark:
• Use an approved spark plug tester.
• DO NOT check for spark with the spark plug removed.
NOTICE Spark plugs have different heat ranges. It is
important that the correct spark plug is used, otherwise,
engine damage can occur. Replace the spark plug with the
same type or equivalent one.
Clean the Spark Plugs
Clean the spark plugs with a wire brush and sturdy knife. DO
NOT use abrasives.
Check the Spark Plug Gap
Use a spark plug feeler gauge (A, Figure 16) to check the
gap between the two electrodes. When the gap is correct, the
gauge will drag slightly as you pull it through the gap.
To adjust the spark plug gap, use a spark plug gauge and
gently bend the curved electrode. Make sure that you do not
touch the center electrode or the porcelain.
Install the Spark Plugs
Tighten the spark plug with your fingers, and then, tighten it
with a wrench as shown in Figure 17.
• 180 in-lbs (20 Nm), OR
• 1/2 turn when you install the original spark plug, OR
• 1/4 turn when you install a new spark plug.
