RouterNode 2, GatewayNode 2,
All manuals and user guides at all-guides.com
SmartBridge
Connections (can only be used on
RouterNode 2)
Environment
Temperature
Humidity
Standard protection rating
Electric
Operating voltage
Output
Output VOUT
Relay output O1
EN
10. Technical specifications
Spring terminal block 10-pin,

wire diameter 0.14 (rigid) or 0.2
(flexible) mm
connector, can only be used
with RouterNode 2)
Operational: -10 °C to +55 °C

Storage: -20 °C to +60 °C

Max. 90%, non-condensing
IP20
9 V to 32 V (reverse polarity
DC DC
protected) or PoE according to
IEEE 802.3af
Power supply via PoE and round
plug possible simultaneously:
round plug > 12 V
used, round plug < 12 V
used
max. 3 W
3.0 V to 3.3 V
DC DC
Max. switching voltage 30

V /24V (resistive load)
DC AC
Max. switching current 1 A

(resistive load)
2 2
to 0.5 mm (IO
→ Round plug
DC
→ PoE
DC
, max. 200 mA
