The following table shows the indicator status and description:
The button Function
Power on
Scroll up
Scroll down
Enter menu
Mute buzzer

4.2 LCD description

The LCD backlight automatically dims after 10 minutes of inactivity. Press any button
to restore the screen.
Press the Button for >100ms & < 1s can power on
the UPS without utility input at the condition of
battery connected
When the Unity is powered on, press the button
Turn on
for >1s can turn on the UPS
Press the button > 3s can turn off the UPS
Turn off
Press to Scroll up the menu option
Press to Scroll down the menu option
Select/Confirm the current selection
Exit the
Press to exit present menu to Main menu or the
present
higher-level menu without changing a setting
menu
Press the button to mute the buzzer temporarily,
once new warning or fault is active, buzzer will
work again
17
Illustration
