Output current (Maximum current in continuous operation)
Frequency inverter nominal power
160 kW
200 kW
250 kW
315 kW
355 kW
400 kW
1)
Power reduction with torsional frequencies below 10 Hz
2) Only with torsional frequencies above 10 Hz
4) Reduction of switching frequency possible on certain conditions
5) As an option, the frequency inverter of this size is available without internal brake
transistor
6) Connection requires a commutating choke.
7) Semiconductor fuses recommended (e.g. Bussmann Type 170M)
8)
For UL-compliant fusing, the specified Cooper Bussmann fuses must be used. * is a
placeholder for assembly.
07/20
2 kHz
305
380
475
595
645
735
Quick Start Guide ANG
Switching frequency
4 kHz
305
380
475
595
645
735
8 kHz
305
380
475
595
645
735
