Note
Position the Pool Wall's Skimmer cutout in the same location to where your electricity
supply will be to power the filtration system (Diagram 20).
Rest the end of the pool
wall in the Side Bottom
Metal Piece between the
gap in the Side Rail. Make
sure the prepared location
is not prone to constant
windy conditions. Continue
unrolling and placing the
bottom edge of the pool
wall into the rails until the
full length of the pool wall
is sitting in the Rails (Dia-
gram 21).
On the opposite side of the pool wall, carefully lift and place the steel wall in between the Side Sup-
port Frame and the Inside Bottom Protector.
Note
There is a section cut
out of the pool wall
that will allow the wall
to slot over the Hori-
zontal Support Beam
(Diagram 22).
Line up the two ends of the pool wall then begin inserting and hand tightening each bolt and nut un-
134
