SQlab pedals 502, 511 and 512
The release force of the pedals
To make the release of the cleats easier or harder, use the adjusting screw from fig. (c + d +f). Turn the preload screw clockwise into
the thread, the resistance is increased and „clicking out" becomes more difficult. Turning the screw counterclockwise, makes the cleat
release easier from the pedal.
Take care with the preload screw, it can fall out if it is turned too far anticlockwise. As soon as you feel greater resistance, do not turn the
screw further counterclockwise.
Note
Hinweis
If you are riding with clipless pedals for the first time, reduce the resistance to „click out", this allows you to get out of the pedal
using less force. Always practice „clicking out" in a safe environment without traffic and other obstacles such as stairs, stones, etc.
In this way you can avoid falls caused by not „clicking out" in time.
Note
The pedals SQlab 502 have four anti­slip nubs Fig. (e).
These are available in two different versions. With the aid
of the anti­slip nubs, you can adjust how good the hold
on the pedal side is without the click system is.
(c)
(e)
Be sure to note the following for the preload screw (f) of
the SQlab 512 model:
If you turn the screw clockwise to make the release more
difficult, the vertically movable marker may be screwed to
the height of the H at most. The mark must not fall below
the H in any case, as this will cause lasting damage to
the pedals.
Warnung
(d)
(f )
