Weight reductions for load handling devices
29 ft offsettable boom extension
*Erected –
29 ft 51 ft tele. boom extension
*Erected (retracted) –
*Erected (extended) –
*Reduction of main boom capacities
Auxiliary boom nose
Hookblocks and headache balls
50 USt, 4-sheave
50 USt, 3-sheave
40 USt, 3-sheave
8.3 USt headache ball (non-swivel)
8.3 USt headache ball (swivel)*
+Refer to rating plate for actual weight.
When lifting over swingaway and/or jib combinations,
deduct total weight of all load handling devices reeved
over main boom nose directly from swingaway or jib
capacity.
NOTE: All load handling devices and boom attachments
are considered part of the load and suitable allowances
MUST BE MADE for their combined weights. Weights are
for Grove furnished equipment.
CENTERLINE
OF BOOM
CG OF
LOAD
DIAGRAM
FOR LIFTING
ON OUTRIGGERS
Bold lines determine the limiting position of any load for operation within working areas indicated.
Grove RT600E
The individual crane's load chart, operating instructions and other instructional plates must be read and understood prior to operating the crane.
Pounds
4412
Pounds
6611
9332
Pounds
137
Pounds
1075
1000
800
350
370
360°
OVER
SIDE
OVER
OVER
FRONT
REAR
OVER
SIDE
THIS CHART IS ONLY A GUIDE AND SHOULD NOT BE USED TO OPERATE THE CRANE.
Load handling
Line pulls and reeving information
Hoists
Main
Main and
auxiliary
The approximate weight of 3/4 in wire rope is 1.5 lb/ft
Wire
rope
layer
1
2
3
4
5
6
Working area diagram
CENTERLINE
OF OUTRIGGER
SUPPORT
BOOM
CENTERED
LONGITUDINAL
OVER FRONT
CENTERLINE
OF CRANE
6°
12°
SEE NOTE
FRONT
AT BOTTOM
CENTERLINE
DIAGRAM
OF ROTATION
FOR LIFTING
ON TIRES
Reeving diagram
Permissable
Nominal cable
Cable specs
line pulls
19 mm (3/4 in)
6 x 37 class, EIPS,
IWRC Special
16,800 lb
Flexible Min.
Breaking Str. 58,800
lb
19 mm (3/4 in) Flex-X
35 Rotation resistant
(non-rotating)
16,800 lb
Min. breaking Str.
85,800 lb
Hoist performance
Hoist line pulls
Drum rope
two-speed hoist
capacity (ft)
Low
High
Layer
Total
available
available
lb*
lb*
18,134
9067
101
101
16,668
8334
110
211
15,420
7710
120
331
14,347
7174
129
460
13,413
6707
139
599
12,594
6297
149
748
* Max lifting capacity:
6 x 37 class or 35 x 7 class = 16,800 lb
REAR AXLE
OSCILLATION
360°
LOCKOUTS MUST
BE SET TO
MAINTAIN 360°
CAPACITIES
C6-829-003529
C6-829-001159
length
450 ft
450 ft
13
