Superstructure Specifications
Boom
33 ft. - 105 ft. (10.1 m - 32 m) four-section, full-power
synchronized boom.
Maximum tip height: 112 ft. (34.1 m).
*Optional Fixed Swingaway Extension
29 ft. (8.8 m) offsettable lattice swingaway extension.
Offsettable at 0°, 25° and 45°. Stows alongside base
boom section. Maximum tip height: 141.5 ft. (43.1 m).
*Optional Telescopic Swingaway Extension
29 ft. - 51 ft. (8.8 m - 15.5 m) telescoping lattice
swingaway extension. Offsettable at 0°, 25° and 45°.
Stows alongside base boom section. Maximum tip
height: 162 ft. (49.3 m).
Boom Nose
Three nylatron sheaves mounted on heavy-duty tapered
roller bearings with removable pin-type rope guards.
*(Four sheaves with optional 18 x 19 wire rope.) Quick-
reeve type boom nose.
*Optional removable auxiliary boom nose with
removable pin type rope guard.
Boom Elevation
One double-acting hydraulic cylinder with integral
holding valve provides elevation from -2° to 78°.
Load Moment
& Anti-Two Block System
Standard "Graphic Display" load moment and anti-two
block system with audio-visual warning and control lever
lockout. These systems provide electronic display of
boom angle, length, radius, tip height, relative load
moment, maximum permissible load, load indication and
warning of impending two-block condition. The system
defaults to 360° on rubber chart. The standard Work
Area Definition System allows the operator to pre-select
and define working areas. If the crane approaches the
pre-set limits, audio-visual warnings aid the operator in
avoiding job-site obstructions.
Cab
Full vision, all steel fabricated with acoustical lining and
tinted safety glass throughout. Deluxe seat incorporates
armrest-mounted hydraulic single-axis controllers. Dash
panel incorporates gauges for all engine functions.
Other standard features include: hot water
heater/defroster, cab circulating air fan, sliding side and
rear windows, sliding skylight with electric wiper and
sunscreen, electric windshield wash/wipe, fire
extinguisher, seat belt and circuit breakers.
4
Swing
Planetary swing with foot-applied multi-disc brake.
Spring applied, hydraulically-released swing brake and
plunger-type, one position, mechanical house lock
operated from cab. *Optional 360° mechanical swing
lock. Maximum speed: 2.5 RPM.
Counterweight
11,250 lbs. (5 103 kg) pinned to superstructure.
Hydraulic System
Three main gear pumps with a combined capacity of
130 GPM (492 L/min).
Maximum operating pressure: 3500 psi (26.2 MPa).
Return line type filter with full flow by-pass protection
and service indicator. Replaceable cartridge with micron
filtration rating of 5/12/16. 134 gallon (509 L) reservoir.
Hydraulic oil cooler (integral with engine radiator).
System pressure test ports.
Hoist Specifications
Main and Auxiliary Hoist:
Grove Model HO30G-16G
Planetary reduction with automatic spring applied multi-
disc brake. Grooved drum. Electronic hoist drum
rotation indicator and hoist drum cable followers.
Maximum Single Line Pull:
Maximum Single Line Speed:
Maximum Permissible Line Pull:
16,800 lbs. (7 620 kg) w/standard 6 x 36 class rope
12,920 lbs. (5 860 kg) w/optional 18 x 19 class rope
Rope Diameter:
Rope Length:
Rope Type:
Optional 18 x 19 class rotation resistant
Maximum Rope Stowage:
18,180 lbs
(8 246 kg)
588 FPM
(179 m/min)
3/4 in. (19 mm)
450 ft. (137 m)
6 x 37 Class EIPS IWRC
694 ft. (211 m)
RT600E Series
