RT650 product guide 45 t 32 m 8,8 - 15,5 m 49 m Rough Terrain Crane • Geländekran Grue Tout-Terrain • Grúa Todo Terreno Autogru Fuoristrada • Grua RT Кран для использования на пересеченной местности www.manitowoccranes.com...
Seite 2
Features • esonderheiten • Caractéristiques • Carasterísticas Caratteristiche • Carasterísticas • Особенности • BOOM: the RT650E incorporates a rectangular boom shape made from 690 MPa steel which eliminates weight and maximizes structural capacities. • AUSLEGER: der RT650E ist mit einem rechteckigen, aus Stahl mit 690 MPa Zugfestigkeit gefertigten Ausleger ausgerüstet, der im Vergleich zu herkömmlichen Ausführungen Gewicht spart und die Tragfähigkeit erhöht.
Support und Schulung, alles unter einem Dach. Dieser Service erstreckt sich auf alle Marken der Manitowoc Crane Group: Potain, Grove, Manitowoc und National Crane. Damit Ihr Kran leistungsfähig bleibt und Ihr Erfolg gesichert ist, bietet Ihnen Manitowoc Crane CARE einen umfassenden Support aus einer Hand. Zu jeder Zeit, an jedem Ort, für jeden Fall – wir sind für Sie da.
Specification Superstructure Carrier Carrier frame Boom Box section frame fabricated from high-strength, low alloy steel. 10,1 m – 32,0 m, four-section, full power boom. Front/rear towing and tie down lugs. Maximum tip height: 34,1 m. Outriggers * Fixed swingaway extension Four hydraulic telescoping single-stage double box beam outriggers with 8,8 m offsettable lattice swingaway extension.
Technische Daten Kranoberwagen Kranunterwagen Ausleger Rahmen Vierteiliger, voll teleskopierbarer Ausleger; 10,1 m bis 32,0 m Länge. Kastenprofilrahmen aus hochfestem Feinkornstahl. Maximale Rollenhöhe 34,1 m. Abschlepp- und Verzurrösen vorne/hinten. *Feststehender Klappspitzenausleger Abstützungen Abwinkelbare Klappspitze in Gitterbauweise, 8,8 m. Abwinkelung 0°, 25° Vier hydraulisch teleskopierbare, einteilige Kastenprofil-Abstützträger mit und 45°.
Caractéristiques techniques Superstructure Châssis Flèche Châssis 10,1-32,0 m, flèche télescopique hydraulique à quatre éléments. Châssis caissonné mécanosoudé en acier à haute limite élastique. Hauteur maximale de tête de flèche : 34,1 m. Chapes de remorquage et d’arrimage à l’avant et à l’arrière. Dispositif de calage * Extension treillis fixe Extension treillis à...
Características Superstructura Chasis Pluma Bastidor Pluma de plena potencia de 4 secciones de 10,1 m – 32,0 m. Estructura tipo cajón fabricada en acero de alta resistencia y baja aleación. Altura máxima en punta al suelo : 34,1 m. Orejetas de amarre delanteras y traseras. Estabilizadores *Extensión fija abatible Extensión abatible de celosía angulable de 8,8 m.
Caratteristiche technique Sovrastruttura Carro Braccio Telaio Braccio a piena potenza a quattro sezioni da 10,1 - 32,0 m. Costruzione in sezioni scatolate realizzate in acciaio al alta resistenza. Altezza massima in punta: 34,1 m. Occhioni di traino e di fissaggio anteriori e posteriori. Stabilizzatori *Prolunga del braccio rotante fissa Quattro stabilizzatori ad azionamento idraulico e cilindri a stelo rovesciato,...
Seite 9
Características Superstrutura Chassis Lança Chassis do transportador Chassis de caixa em aço de alta resistência. Olhais de fixação e de Lança de quatro secções, potência total, 10,1 m – 32,0 m. reboque dianteiros e traseiros. Altura máxima da ponta da lança : 34,1 m. Estabilizadores * Extensão swingaway fixa Quatro vigas de estabilização hidráulicas e telescópicas, de caixa dupla,...
Технические характеристики Крановая установка Тягач Стрела Шасси Четырехсекционная, синхронизированная, Коробчатая рама выполнена из высокопрочной низколегированной стали. телескопическая стрела длиной 10,1 – 32,0 м. Передние/задние буксировочные и крепежные проушины. Максимальная высота оголовка стрелы: 34,1 м. Выносные опоры *Удлинитель стрелы Четыре гидравлические телескопические одноступенчатые Двойной...
Data • Daten • Caractéristiques • Datos • Dati • Características • Данные Axle Total weight Achse Gesamtgewicht Essieu Poids total Peso total Asse Peso totale Eixos Peso total Суммарный вес Ось Basic machine • Grundausführung • Configuration standard 14,9 17,6 32,5 Maquina básica •...
Load charts • Traglasten • Capacités de levage • Capacidades Capacità • Diagramas de carga • Таблицы грузоподъемности Notes • Hinweise • Notes • Notas • Note • Notas • Примечания Lifting capacities according to DIN/ISO • 85% Warning: THIS CHART IS ONLY A GUIDE. The Notes below are for illustration only and should not be relied upon to operate the crane. The individual crane’s load chart, operating instructions and other instruction plates must be read and understood prior to operating the crane.
Load charts • Traglasten • Capacités de levage • Capacidades Capacità • Diagramas de carga • Таблицы грузоподъемности Working range • Arbeitsbereiche • Diagramme de levage • Gama de trabajo • Area di lavoro Intervalo de funcionamento • Грузовысотные характеристики 5,5 t 10,1 - 32,0 m 100%...
Load charts • Traglasten • Capacités de levage • Capacidades Capacità • Diagramas de carga • Таблицы грузоподъемности Weight reductions • Gewichtsreduzierung durch Lastaufnahmemittel • Reductions de charge Reducciones de peso • Riduzioni di peso • Reduções de peso • Снижение веса Auxiliary boom nose / Zusatz-Auslegerkopf / Tête de flèche auxiliaire / Cabeza auxiliar / Falconcino ausiliario in testa al braccio Cabeçote da lança auxiliar / Вспомогательный...
Seite 24
Distributed By: Manitowoc Crane Group - Americas - World Headquarters 2400 S. 44th Street • Manitowoc • WI 54220 USA Tel: +1 920 684 4410 • Fax: +1 920 652 9778 Manitowoc Crane Group - Europe, Middle East & Africa Manitowoc Crane Group France S.A.S.
Seite 26
Dimensions Note: ( ) Reference dimensions in mm RT600E Series...
Seite 27
Working Range Tele-Swingaway 33 - 105 ft. 29 - 51 ft. 11,250 lbs. 100% 360° (10.1 - 32 m) (8.8 - 15.5 m) (5103 kg) 0° 51' EXT. 25° 45° 29' EXT. 70° 60° 50° 40° 30° 20° 78° 10° MAX.
Seite 28
Superstructure Specifications Boom Swing 33 ft. - 105 ft. (10.1 m - 32 m) four-section, full-power Planetary swing with foot-applied multi-disc brake. synchronized boom. Spring applied, hydraulically-released swing brake and Maximum tip height: 112 ft. (34.1 m). plunger-type, one position, mechanical house lock operated from cab.
Seite 29
Carrier Specifications Chassis Brakes Box section frame fabricated from high-strength, low Full hydraulic split circuit disc-type brakes operating on alloy steel. Integral outrigger housings and front/rear all wheels. Spring-applied, hydraulically released towing and tie down lugs. transmission-mounted parking brake. Outrigger System Tires Four hydraulic telescoping single-stage double box *23.5 x 25 - 20PR bias earthmover type.
Seite 30
RT650E RATED LIFTING CAPACITIES IN POUNDS 33 FT. - 105 FT. BOOM ON OUTRIGGERS FULLY EXTENDED - 360° #0001 Radius Main Boom Length in Feet Feet 100,000 80,550 67,250 (69.5) (73.5) (77) 87,100 79,150 64,200 *56,100 (65.5) (70.5) (75) (78) 69,050 69,550 59,950...
Seite 31
RT640E RATED LIFTING CAPACITIES IN POUNDS 33 FT. - 105 FT. BOOM ON OUTRIGGERS FULLY EXTENDED - 360° #0001 Radius Main Boom Length in Feet Feet 80,000 73,500 67,200 (69.5) (73.5) (77) 77,750 69,500 62,300 *56,100 (65.5) (70.5) (75) (78) 69,050 65,550 57,300...
Seite 32
RT600E SERIES 29 FT. - 51 FT. TELE OFFSETTABLE BOOM EXTENSION ON OUTRIGGERS FULLY EXTENDED - 360° **29 ft. LENGTH 51 ft. LENGTH NOTES: Radius #0021 #0022 #0023 #0041 #0042 #0043 1. All capacities above the bold line are Feet 0°...
Seite 33
RT600E SERIES ON RUBBER CAPACITIES STATIONARY CAPACITIES STATIONARY CAPACITIES 360° DEFINED ARC OVER FRONT (See Note 3) #9005 #9005 Radius Radius Main Boom Length in Feet Main Boom Length in Feet Feet Feet 46,600 40,800 34,600 38,550 38,550 (69.5) (73.5) (77) (69.5) (73.5)
Seite 34
RT600E SERIES ON RUBBER CAPACITIES (cont'd.) PICK & CARRY CAPACITIES (UP TO 2.5 MPH) - BOOM CENTERED OVER FRONT (See note 7) NOTES TO ALL RUBBER CAPACITY CHARTS: #9006 Radius 1. Capacities are in pounds and do not exceed 75% of Main Boom Length in Feet tipping loads as determined by test in accordance Feet...
Seite 35
WEIGHT REDUCTIONS FOR LOAD HANDLING DEVICES 29 FT. OFFSETTABLE BOOM EXTENSION *Erected - 4,412 lb. 29 FT. - 51 FT. TELE. BOOM EXTENSION *Erected (Retracted) - 6,611 lb. *Erected (Extended) - 9,332 lb. *Reduction of main boom capacities AUXILIARY BOOM NOSE 137 lb.
Seite 36
LINE PULLS AND REEVING INFORMATION PERMISSIBLE NOMINAL HOISTS CABLE SPECS. LINE PULLS CABLE LENGTH 3/4" (19 mm) 18x19 Class Main & Aux. Rotation Resistant 12,920 lb. 450 ft. Min. Breaking Str. 64,600 lb. 3/4" (19 mm) 6x37 Class, Main & Aux. EIPS, IWRC Special Flexible 16,800 lb.
Seite 37
CENTERLINE 360° CENTERLINE OVER OF OUTRIGGER OF BOOM SIDE SUPPORT LONGITUDINAL CENTERLINE OF CRANE CG OF OVER OVER LOAD FRONT REAR SEE NOTE AT BOTTOM DIAGRAM FOR LIFTING CENTERLINE OVER ON OUTRIGGERS OF ROTATION SIDE REAR AXLE OSCILLATION 360° LOCKOUTS MUST BE SET TO MAINTAIN 360°...
Seite 38
Grove Worldwide - World Grove Asia/Pacific - Regional Office Headquarters Asia/Pacific, Near East Western Hemisphere, Asia/Pacific 171 Chin Swee Road 1565 Buchanan Trail East #10-09 San Centre P.O. Box 21 Singapore 16987 Shady Grove, Pennsylvania 17256, Tel: [Int + 65] 536-6112 U.S.A.
Grove RT650E Product Guide 45 t 32 m 8,8 - 15,5 m 49 m Rough Terrain Crane • Geländekran Grue Tout-Terrain • Grúa Todo Terreno Autogru Fuoristrada • Grua RT Кран для использования на пересеченной местности...
Seite 40
Features • Besonderheiten • Caractéristiques • Carasterísticas Caratteristiche • Carasterísticas • Особенности • BOOM: the RT650E incorporates a rectangular boom shape made from 690 MPa steel which eliminates weight and maximizes structural capacities. • AUSLEGER: der RT650E ist mit einem rechteckigen, aus Stahl mit 690 MPa Zugfestigkeit gefertigten Ausleger ausgerüstet, der im Vergleich zu herkömmlichen Ausführungen Gewicht spart und die Tragfähigkeit erhöht.
Seite 41
Crane. Para assegurar a manutenção cuidada das suas gruas e a prosperidade do seu negócio, o seu único interlocutor do serviço de clientes é a Manitowoc Crane CARE. Esteja onde estiver, sejam as horas que forem, precise do que precisar, pode sempre contar connosco! Manitowoc Crane Care - это...
Specification Superstructure Carrier Boom Carrier frame 10,1 m – 32,0 m, four-section, full power boom. Box section frame fabricated from high-strength, low alloy steel. Maximum tip height: 34,1 m. Front/rear towing and tie down lugs. *Fixed swingaway extension Outriggers 8,8 m offsettable lattice swingaway extension. Offsets 0°, 25° and 45°. Four hydraulic telescoping single-stage double box beam outriggers with inverted Stows alongside base boom section.
Technische Daten Kranoberwagen Kranunterwagen Ausleger Rahmen Vierteiliger, voll teleskopierbarer Ausleger; 10,1 m bis 32,0 m Länge. Kastenprofilrahmen aus hochfestem Feinkornstahl. Maximale Rollenhöhe 34,1 m. Abschlepp- und Verzurrösen vorne/hinten. *Feststehender Klappspitzenausleger Abstützungen Abwinkelbare Klappspitze in Gitterbauweise, 8,8 m. Abwinkelung 0°, 25° und 45°. Vier hydraulisch teleskopierbare, einteilige Kastenprofil-Abstützträger mit innen Seitlich am Ausleger montierbar.
Caractéristiques techniques Superstructure Châssis Flèche Châssis 10,1-32,0 m, flèche télescopique hydraulique à quatre éléments. Châssis caissonné mécanosoudé en acier à haute limite élastique. Hauteur maximale de tête de flèche : 34,1 m. Chapes de remorquage et d’arrimage à l’avant et à l’arrière. *Extension treillis fixe Dispositif de calage Extension treillis à...
Características Superstructura Chasis Pluma Bastidor Pluma telescópica de cuatro secciones totalmente hidráulica de 10,1 m - 32,0 m. Estructura tipo cajón fabricada en acero de alta resistencia y baja aleación. Altura máxima en punta al suelo : 34,1 m. Orejetas de amarre delanteras y traseras. *Extensión fija abatible Estabilizadores Extensión abatible de celosía angulable de 8,8 m.
Caratteristiche tecniche Sovrastruttura Carro Braccio Telaio Braccio con sfilamento idraulico sincronizzato a quattro sezioni da 10,1 a 32,0 m. Costruzione in sezioni scatolate realizzate in acciaio al alta resistenza. Altezza massima in punta: 34,1 m. Occhioni di traino e di fissaggio anteriori e posteriori. *Jib ripiegabile Stabilizzatori Jib tralicciato inclinabile da 8,8 m.
Seite 47
Características Superstrutura Chassis Lança Chassis do transportador 10,1 m - 32,0 m. Lança de quatro secções, potência total. Chassis de caixa em aço de alta resistência. Olhais de fixação e de reboque dianteiros Altura máxima da ponta da lança : 34,1 m. e traseiros.
Технические характеристики Крановая установка Тягач Стрела Шасси Четырехсекционная, синхронизированная, Коробчатая рама выполнена из высокопрочной низколегированной стали. телескопическая стрела длиной 10,1 - 32,0 м. Передние/задние буксировочные и крепежные проушины. Максимальная высота оголовка стрелы: 34,1 м. Выносные опоры *Удлинитель стрелы Четыре гидравлические телескопические одноступенчатые двухмуфтовые Двойной...
Data • Daten • Caractéristiques • Datos • Dati • Características• Данные Total weight • Gesamtgewicht Axle • Achse Poids total • Peso total Essieu • Eje Peso totale • Peso total Asse • Eixos • Оси Суммарный вес Basic machine • Grundausführung • Configuration standard 14,9 17,6 32,5...
Load charts • Traglasten • Capacités de levage • Capacidades Capacità • Diagramas de carga • Таблицы грузоподъемности Notes • Hinweise • Notes • Notas • Note • Notas • Примечания Lifting capacities according to DIN/ISO • 85% Warning: THIS CHART IS ONLY A GUIDE. The Notes below are for illustration only and should not be relied upon to operate the crane. The individual crane’s load chart, operating instructions and other instruction plates must be read and understood prior to operating the crane.
Seite 52
Load charts • Traglasten • Capacités de levage • Capacidades Capacità • Diagramas de carga • Таблицы грузоподъемности Working range • Arbeitsbereiche • Diagramme de levage • Gama de trabajo • Area di lavoro Intervalo de funcionamento • Грузовысотные характеристики 10,1 - 32,0 m 100 % 360°...
Seite 53
Load charts • Traglasten • Capacités de levage • Capacidades Capacità • Diagramas de carga • Таблицы грузоподъемности Telescopic boom • Teleskopausleger • Flèche principale • Pluma telescópica • Braccio telescopico Lança telescópica • Телескопическая стрела 10,1 - 32,0 m 100 % 360°...
Seite 54
Load charts • Traglasten • Capacités de levage • Capacidades Capacità • Diagramas de carga • Таблицы грузоподъемности Telescopic boom • Teleskopausleger • Flèche principale • Pluma telescópica • Braccio telescopico Lança telescópica • Телескопическая стрела 10,1 - 32,0 m 50 % 360°...
Seite 55
Load charts • Traglasten • Capacités de levage • Capacidades Capacità • Diagramas de carga • Таблицы грузоподъемности Telescopic boom • Teleskopausleger • Flèche principale • Pluma telescópica • Braccio telescopico Lança telescópica • Телескопическая стрела 10,1 - 32,0 m 0 km/h 360°...
Seite 56
Load charts • Traglasten • Capacités de levage • Capacidades Capacità • Diagramas de carga • Таблицы грузоподъемности Telescopic boom • Teleskopausleger • Flèche principale • Pluma telescópica • Braccio telescopico Lança telescópica • Телескопическая стрела 10,1 - 32,0 m 4 km/h 0°...
Seite 57
Load charts • Traglasten • Capacités de levage • Capacidades Capacità • Diagramas de carga • Таблицы грузоподъемности Swingaway • Klappspitze • Extension treillis • Plumín • Falcone • Swingaway • Складной удлинитель стрелы 10,1 - 32,0 m 8,8 - 15,5 m 100 % 360°...
Seite 58
Load charts • Traglasten • Capacités de levage • Capacidades Capacità • Diagramas de carga • Таблицы грузоподъемности Weight reductions • Gewichtsreduzierung durch Lastaufnahmemittel • Reductions de charge Reducciones de peso • Riduzioni di peso • Reduções de peso • Снижение веса Auxiliary boom nose / Zusatz-Auslegerkopf / Tête de flèche auxiliaire / Cabeza auxiliar / Falconcino ausiliario in testa al 62 kg braccio / Cabeçote da lança auxiliar / Вспомогательный...
Seite 62
Regional headquarters Manitowoc - Americas Manitowoc - Europe, Middle East & Africa Manitowoc - Asia Pacifi c Manitowoc, Wisconsin, USA Ecully, France Shanghai, China Tel: +1 920 684 6621 Tel: +33 (0)4 72 18 20 20 Tel: +86 21 6457 0066...
Seite 63
Grove RT600E Product Guide Features • 10 m - 32 m (33 ft - 105 ft) four-section full power boom • 8,8 m – 15,5 m (29 ft – 51 ft) telescopic swingaway extension • Maximum main boom tip height of 34 m (112 ft) •...
Seite 64
Features The RT600E cab includes: • hot water heater/defroster • single axis joystick controllers • sliding skylight and adjustable sunscreen • engine instrumentation • full accoustical lining The PAT iFlex 5 graphic display LMI includes a work area definition system which allows the operator to define a preferred working area.
Seite 65
Contents Specifications Dimensions and weights Working range Load charts Load handling Notes...
Specifications Superstructure Boom Full vision, all steel fabricated with acoustical lining and tinted safety glass throughout. Deluxe seat 10,1 m - 32 m (33 ft - 105 ft) four-section, full-power incorporates armrest-mounted hydraulic single-axis synchronized boom. controllers. Dash panel incorporates gauges for all Maximum tip height: 34,1 m (112 ft).
Seite 67
Specifications Carrier Steering Chassis Fully independent power steering: Box section frame fabricated from high-strength, low alloy steel. Integral outrigger housings and front/rear Front: Full hydraulic, steering wheel controlled. lifting, towing, and tie down lugs. Rear: Full hydraulic, switch controlled. Provides infinite variations of 4 main steering modes: Outrigger system front only, rear only, crab, and coordinated.
Seite 68
Specifications Carrier continued Miscellaneous standard equipment Full width steel fenders, dual rear view mirrors, hookblock tiedown, electronic back-up alarm, light package, front stowage well, tachometer, rear wheel position indicator, 36,000 BTU hot water heater, air conditioning, hoist mirrors, engine distress A/V warning system.
Dimensions and weights Dimensions 508 mm (1'-8") 12 448,3 mm (41'-11") 3894,6 mm (12'-9") 286 mm 965,2 mm 838,2 mm (11.25") (3'-2") (2'-9") 967 mm (38.06") 1700,2 mm (5'-7") 3497,4 mm 3531 mm (11'-6") (11'-7.0") 4743,5 mm 1645,0 mm 781,0 mm (15'-7") 21.30°...
Load charts �� ft���� ft ��,��� lb Stationary Defined arc over front Pick & carry Boom centered up to �.� mph over front Pounds Pounds ����� Main boom length in feet Main boom length in feet Feet Feet �� �� ��...
Load handling Weight reductions for load handling devices Reeving diagram 29 ft offsettable boom extension Pounds *Erected – 4412 29 ft 51 ft tele. boom extension Pounds *Erected (retracted) – 6611 *Erected (extended) – 9332 *Reduction of main boom capacities Auxiliary boom nose Pounds Line pulls and reeving information...
