RT600E Series
WEIGHT REDUCTIONS FOR
LOAD HANDLING DEVICES
29 FT. OFFSETTABLE
BOOM EXTENSION
*Erected -
29 FT. - 51 FT. TELE.
BOOM EXTENSION
*Erected (Retracted) -
*Erected (Extended) -
*Reduction of main boom capacities
AUXILIARY BOOM NOSE
HOOKBLOCKS and HEADACHE BALLS:
50 Ton, 4 Sheave
50 Ton, 3 Sheave*
40 Ton, 3 Sheave
22 ton, 2 Sheave
8.3 Ton Headache Ball (non-swivel)
8.3 Ton Headache Ball (swivel)*
* DO NOT use with 18x19 class of rope.
+Refer to rating plate for actual weight.
When lifting over swingaway and/or jib combina-
tions, deduct total weight of all load handling
devices reeved over main boom nose directly
from swingaway or jib capacity.
NOTE: All load handling devices and boom at-
tachments are considered part of the load and
suitable allowances MUST BE MADE for their
combined weights. Weights are for Grove fur-
nished equipment.
4,412 lb.
6,611 lb.
9,332 lb.
137 lb.
1075 lb.+
1000 lb.+
785 lb.+
800 lb.+
350 lb.+
214 lb.+
11
