Specification
Superstructure
Boom
10,1 m – 32,0 m, four-section, full power boom.
Maximum tip height: 34,1 m.
*Fixed swingaway extension
8,8 m offsettable lattice swingaway extension. Offsets 0°, 25° and 45°.
Stows alongside base boom section.
Maximum tip height: 43,1 m.
*Telescopic Swingaway extension
8,8 m - 15,5 m telescoping lattice swingaway extension. Offsets at 0°, 25° and 45°.
Stows alongside base boom section.
Maximum tip height: 49,3 m.
Boom elevation
One double acting hydraulic cylinder with integral holding valve provides elevation
from -2° to +78°.
Load moment and anti-two block system
Standard "Graphic Display" load moment and anti-two block system with audio-
visual warning and control lever lockout. These systems provide electronic display of
boom angle, length, radius, tip height, relative load moment, maximum permissible
load, load indication and warning of impending two-block condition. The standard
Work Area Definition System allows the operator to pre-select and define safe
working areas. If the crane approaches the pre-set limits, audio-visual warnings aid
the operator in avoiding job-site obstructions.
Cab
Full-vision, all-steel fabricated with acoustical lining and tinted safety glass
throughout. Deluxe seat incorporates armrest-mounted hydraulic single-axis
controllers. Dash panel incorporates gauges for all engine functions. Other standard
features include: hot water heater, cab circulating air fan, sliding side and rear
windows, sliding skylight with electric wiper and sunscreen, electric windshield
wash/wipe, fire extinguisher and seat belt, AC.
Slewing
Planetary swing drive with foot applied multi-disc wet brake. Spring applied,
hydraulically released swing brake. Single position mechanical house lock, operated
from cab.
Maximum speed: 2,5 RPM.
Counterweight
5 556 kg pinned to structure.
Hydraulic system
Three main gear pumps with combined capacity of 391 L/min. Maximum operating
pressure: 262 BAR. Return line type filter with full flow by-pass protection and
service indicator. Replaceable cartridge with micron filtration rating of 5/12/16.
509 L Hyd. reservoir. Hydraulic oil cooler. System pressure test ports.
Manual hyd. pump disconnect.
Hoist
Planetary reduction with automatic spring applied multi-disc wet brake.
Grooved drum. Electronic hoist drum rotation indicators, and hoist drum cable
followers.
Maximum Single Line Pull:
• 1st layer:
8 246 kg.
• 5th layer:
6 084 kg.
Maximum Permissible Line Pull: 7 620 kg with 6X37 class rope.
7 620 kg. with 35X7 Rotation Resistant rope.
Maximum Single Line Speed: 179 m/min.
Rope Construction: 6X36 EIPS IWRC, Special Flexible
35x7 Flex-X, Rotation Resistant
Rope Diameter: 19mm.
Rope Length: Main Hoist: 137 m.
Maximum Rope Stowage: 211 m.
4
• 3rd layer:
6 994 kg.
Carrier
Carrier frame
Box section frame fabricated from high-strength, low alloy steel.
Front/rear towing and tie down lugs.
Outriggers
Four hydraulic telescoping single-stage double box beam outriggers with inverted
jacks and integral holding valves.
Three position setting, 0%, 50% and fully extended.
All steel fabricated, quick release type outrigger floats, 610 mm diameter.
Maximum outrigger pad load: 31 344 kg.
Controls and crane level indicator located in cab.
Engine
Cummins QSB 6,7L diesel, six cylinders, 173 bhp, 129 kW (Gross)
at 2 500 RPM. Maximum torque: 800 Nm at 1 500 RPM.
Transmission
Full rangeshift with 6 forward and 3 reverse speeds.
Front axle disconnect for 4 x 2 travel.
Drive/Steer
4 x 4.
Fully independent power steering:
Front: Full hydraulic steering wheel controlled.
Rear: Full hydraulic switch controlled.
Provides infinite variations of 4 main steering modes: front only, rear only, crab and
coordinated. Rear steer indicator. Turning radius: 6,4 m.
Axles
Front: Drive/steer with differential and planetary reduction hubs rigid mounted to
frame.
Rear: Drive/steer with differential and planetary reduction hubs pivot mounted to
frame.
Tyres
Std. 23,5 x 25 - 20 bias ply, Earthmover type.
Brakes
Full hydraulic split circuit operating on all wheels. Spring-applied,
hydraulically released parking brake mounted on front axle.
Lights
Full lighting including turn indicators, head, tail, brake and hazard warning lights.
Maximum speed
39 km/h.
Gradeability (theoretical)
78 %, 23,5 x 25 tyres, pumps engaged, 32,0 m boom, and tele-swingaway.
Electrical system
Two 12 V - maintenance free batteries. 12 V starting and lighting.
Battery disconnect switch.
* Optional equipment
• CE Mark conformance
• Auxiliary lighting package (includes cab mounted amber flashing light, hoist
mounted work light, and dual base boom mounted floodlights).
• LMI light bar (in cab).
• 360˚ NyC style mechanical swing lock.
• Rear Pintle hook.
• Cab controlled cross axle differential locks, (front and rear).
• PAT data logger.
• Rubber mat for storage trough.
*Denotes optional equipment
