Specifications
Superstructure
Boom
10,1 m - 32 m (33 ft - 105 ft) four-section, full-power
synchronized boom.
Maximum tip height: 34,1 m (112 ft).
8,8 m (29 ft) offsettable lattice swingaway extension.
Offsettable at 0°, 25° and 45°. Stows alongside base
boom section.
Maximum tip height: 43,1 m (141.5 ft).
8,8 m - 15,5 m (29 ft - 51 ft) telescoping lattice
swingaway extension. Offsettable at 0°, 25° and 45°.
Stows alongside base boom section.
Maximum tip height: 49,3 m (162 ft).
Boom nose
Three nylatron sheaves mounted on heavy-duty tapered
roller bearings with removable pin-type rope guards.
Quick-reeve type boom nose.
*Optional removable auxiliary boom nose with
removable pin type rope guard.
Boom elevation
One double-acting hydraulic cylinder with integral
holding valve provides elevation from -2° to 78°.
Load moment and anti-two
block system
Standard "Graphic Display" load moment and anti-two
block system with audio-visual warning and control
lever lockout. These systems provide electronic display
of boom angle, length, radius, tip height, relative load
moment, maximum permissible load, load indication
and warning of impending two-block condition. The
system defaults to 360° on rubber chart. The standard
Work Area Definition System allows the operator
to pre-select and define working areas. If the crane
approaches the pre-set limits, audio-visual warnings aid
the operator in avoiding job-site obstructions.
Counterweight
5556 kg (12,250 lb) pinned to superstructure.
4
* Optional fixed
swingaway extension
* Optional telescopic
swingaway extension
*Denotes optional equipment
Cab
Full vision, all steel fabricated with acoustical lining
and tinted safety glass throughout. Deluxe seat
incorporates armrest-mounted hydraulic single-axis
controllers. Dash panel incorporates gauges for all
engine functions. Other standard features include: hot
water heater/defroster, air conditioning, cab circulating
air fan, sliding side and rear windows, sliding skylight
with electric wiper and sunscreen, electric windshield
wash/wipe, fire extinguisher, seat belt and circuit
breakers.
Swing
Planetary swing with foot-applied multi-disc brake.
Spring applied, hydraulically-released swing brake and
plunger-type, one position, mechanical house lock
operated from cab.
*Optional 360° mechanical swing lock. Maximum
speed: 2.5 rpm.
Hydraulic system
Three main gear pumps with combined capacity of
391 L/min (103 GPM), 511 L/min (135 GPM) with
optional air conditioning.
Maximum operating pressure: 26.2 MPa (3500 psi)
Return line type filter with full flow by-pass protection
and service indicator. Replaceable cartridge with
micron filtration rating of 5/12/16. 509 L (134 gal)
reservoir. Hydraulic oil cooler. System pressure test
ports. Manual hydraulic pump disconnect.
Hoist Specifications (HP30G) main
and auxiliary hoist
Planetary reduction with automatic spring applied
multi-disc brake. Grooved drum. Electronic hoist drum
rotation indicator and hoist drum cable followers.
Maximum single line pull: 8246 kg (18,180 lb)
Maximum single line speed: 179 m/min (588 FPM)
Maximum permissible line pull:
7620 kg (16,800 lb) with standard 6 x 37 class rope
7620 kg (16,800 lb) with optional 35 x 7 class rope
Rope diameter: 19 mm (3/4 in)
Rope length: 137 m (450 ft)
Rope type: 6 x 37 Class EIPS IWRC
Optional rope type: 35 x 7 class rotation resistant
Maximum usable rope stowage: 211 m (694 ft)
