STATIONARY CAPACITIES
Radius
in
Main Boom Length in Feet
Feet
33 40
38,550 38,550
10
(69.5) (73.5)
32,550 32,550
12
(65.5) (70.5)
23,700 23,700
15
(59.5) (65.5)
14,450 14,450
20
(47.5) (57)
9,640 9,640
25
(32) (47)
6,840
30
(34.5)
35
40
45
50
Min. boom angle (°) for indicated length (no load)
Max. boom length (ft.) at 0° boom angle (no load)
NOTE: ( ) Boom angles are in degrees.
#LMI operating code. Refer to LMI manual for operating
instructions.
Lifting Capacities at Zero Degree Boom Angle
On Rubber - 360°
Main Boom Length in Feet
Boom
Angle
33 40
7,580 4,850
0°
(28.2) (35)
NOTE: ( ) Reference radii in feet.
RT600E Series
RT600E SERIES ON RUBBER CAPACITIES
360°
#9005
50 60
32,550
(74.5)
23,700 23,700
(71) (75.5)
14,450 14,450 14,450
(64.5) (70) (73.5)
9,640 9,640 9,640
(58) (65) (69.5)
6,840 6,840 6,840
(50) (59) (64.5)
4,850 4,850 4,850
(41.5) (53) (60)
3,450 3,450 3,450
(30.5) (46.5) (54.5)
2,410 2,410
(38.5) (49)
1,610 1,610
(28.5) (43)
50
2,410
(45)
A6-829-100836A
STATIONARY CAPACITIES
DEFINED ARC OVER FRONT (See Note 3)
Radius
in
Feet
33
70
46,600
10
(69.5)
40,800
12
(65.5)
34,000
15
(59.5)
26,050
20
(47.5)
18,200
25
(32)
30
35
40
45
50
55
30
60
60
Min. boom angle (°) for indicated length (no load)
Max. boom length (ft.) at 0° boom angle (no load)
NOTE: ( ) Boom angles are in degrees.
#LMI operating code. Refer to LMI manual for operating
instructions.
Lifting Capacities at Zero Degree Boom Angle
On Rubber - Defined Arc Over Front
Boom
Angle
33
14,550
0°
(28.2)
NOTE: ( ) Reference radii in feet.
#9005
Main Boom Length in Feet
40 50 60
40,800 34,600
(73.5) (77)
40,800 34,600
(70.5) (74.5)
34,000 34,000 26,650
(65.5) (71) (75.5)
26,050 26,050 26,050
(57) (64.5) (70)
18,200 18,200 18,200
(47) (58) (65)
13,100 13,100 13,100
(34.5) (50) (59)
10,050 10,050
(41.5) (53)
7,900 7,900
(30.5) (46.5)
6,290
(38.5)
5,050
(28.5)
Main Boom Length in Feet
40 50 60
10,050 6,290 4,060
(35) (45) (55)
A6-829-100835A
70
21,500
(78)
21,500
(73.5)
18,200
(69.5)
13,100
(64.5)
10,050
(60)
7,900
(54.5)
6,290
(49)
5,050
(43)
4,060
(35.5)
3,260
(26.5)
0
70
70
2,590
(65)
