NOTICE
Charge the battery before use. Recharge Li-Ion batteries regularly to avoid
discharge.
Onl use a REMS rapid charger for charging. New Li-Ion batteries and Li-Ion
batteries which have not been used for a long time onl reach full capacit after
several charges. Non-rechargeable batteries ma not be charged.
The left control lamp lights up and remains green when the mains plug is
plugged in. If a batter is inserted in the rapid charger, the green control lamp
ashes to indicate that the batter is charging. The green light stops ashing
and remains on to signal that the batter is full charged. If the red control lamp
ashes, the batter is defective. If the red control lamp comes on and remains
on, this indicates that the temperature of the rapid charger is outside the permis-
sible range of 0°C to +45°C.
NOTICE
The rapid chargers are not suitable for outdoor use.
2.2. Installing the Machine
Place he electric pipe cutting machine on a REMS Jumbo E or REMS Jumbo
collapsible workbench (accessor , Art. No. 120240 or 120200). Alternativel ,
unscrew the pipe arm (2) and clamp the basic bod (1) in the vice (Fig. 3) or
bolt the basic bod to a form base with screws through the holes (3). Longer
pipes must be supported on bo h sides of the machine if necessar with REMS
Herkules 3B or REMS Herkules Y (accessor , Art. No. 120120 or 120130).
Pull out he mains plug or remove the batter ! Choose suitable cutting wheel:
REMS cutting wheel Cu-INOX for stainless steel pipes, steel pipes and
copper pipes of the press tting s stems
REMS cutting wheel V for composite pipes.
Remove hexagon nut (5) with single open-ended wrench size 8. Insert (change)
cut ing wheel (4). Make sure that the cams of the drive shaft engage in the
drivers of the cutting wheel. Replace he hexagon nut (5)
NOTICE
Use onl an original REMS cutting wheels! An unsuitable cutting wheel will be
damaged or the pipe will not be cut.

3. Operation

CAUTION
Danger of injury!
Wear suitable clothing. Do not wear loose clothing or jewellery. Keep hair,
long hair can get caught in moving parts.
3.1. Work procedure
Pull up the handle (7) until the pipe to be cut can be placed on the pipe rest
5. Behaviour in the event of faults
5.1. Fault: Electric pipe cutting machine, cordless pipe cutting machine comes to a standstill during cutting.
Cause:
Feeding pressure too high.
Blunt/broken cutting wheel.
Worn carbon brushes.
Batter at or defective (REMS Akku-Nano).
5.2. Fault: Pipe stops during cutting.
Cause:
Pipe not round.
Pipe not deburred on the outside.
Rollers of the pipe rest (6) soiled.
5.3. Fault: Pipe is not cut.
Cause:
Unsuitable cutting wheel.
Pipe not round.
Pipe not deburred on the outside.
Cutting wheel damaged.
1 2
Loose clothing, jewellery or
(6). Outside burr (sawing burr) must be removed from he pipe otherwise the
rollers will be damaged. Make sure that the a cutting wheel (4) suitable for the
pipe to be cut is selected/ tted. Do not allow he pipe to knock against the
cutting wheel when inserting, the cutting wheel could be damaged. Mark the
cutting point on the pipe and position it to the cutting wheel. Support longer
pipes (see 3.2). Press the safet inching switch (8), press the handle (7) against
the pipe rest and cut the pipe.
NOTICE
If the cutting wheel breaks during cutting, the same cutting notch in he pipe to
be cut ma not be used after changing he cutting wheel. The changed cutting
wheel will be damaged b fragments left in the cutting notch.
3.2. Supporting the Material
CAUTION
Alwa s support pipes and longer pipe sections, on both sides if necessar , e.g.
with height-adjustable REMS Herkules 3B or REMS Herkules Y material rests
(accessor , Art. No. 120120 or 120130). Make sure that the height-adjustable
material rest is set to the same height of the pipe rest (6). This reduces untrue
running and uncontrolled falling of the pipe to the ground.
3.3. Low Discharge Protection
REMS Akku-Nano is e uipped with low discharge protection for the batter .
This switches off the power tool as soon as the batter needs to be recharged.
In this case remove the batter and charge with the REMS rapid charger.

4. Maintenance

4.1. Maintenance
WARNING
Keep the rollers of the pipe rest (6), cut ing wheel (4) and cutting wheel holder
clean. Clean heavil soiled metal parts with the REMS CleanM machine cleaner
(Art. No. 140119) and then protect against rust.
Clean plastic parts (e.g. housing) onl with REMS CleanM machine cleaner
(Art. No. 140119) or a mild soap and a damp cloth. Do not use household
cleaners. These often contain chemicals which can damage the plastic parts.
Never use petrol, turpentine, thinner or similar products for cleaning.
Make sure that liquids never get onto or inside the power tool. Never immerse
the power tool in liquid.
WARNING
work ma onl be performed b quali ed personnel.
The gear REMS Nano, REMS Akku-Nano runs in a life-long grease lling and
therefore needs no lubrication. The motors of REMS Nano and REMS Akku-
Nano have carbon brushes. These are subject to wear and must therefore be
checked b quali ed specialists or an authorised REMS customer service
workshop from time to time. The carbon brushes cannot be replaced so that
the motor ma have to be changed. See also page 5. Behaviour in the event
of faults
Reduce feeding pressure.
Change cutting wheel.
Have the motor changed b an authorised REMS customer service workshop.
Charge the batter with the Li-Ion/Ni-Cd rapid charger or change the batter .
Reduce feeding pressure.
Deburr pipe on outside.
Clean rollers, see 4.1.
Select and change cutting wheel according to the pipe to be cut.
Reduce feeding pressure.
Deburr pipe on outside.
Change cutting wheel.
