SETTING 2: MANUALLY SETTING THE LOWER END LIMIT AND AUTOMATICLY SETTING THE UP
END LIMIT (PRODUCT WITH AUTOMATIC BOTTOM LOCK SYSTEM PROHIBITED):
1- Press the « DOWN » button: the product will run down automatically if the button is held for 2 s. Stop the
product with the « STOP » button at the desired down limit.
2- If necessary adjust the position with the "UP" and "DOWN" buttons.
3- Press simultaneously on the « STOP » and « UP » buttons: the product will run up. Press "STOP" button to
stop the product (Optional).
4- Press 2 s on the "STOP" button to confirm the settings, the motor jogs. The operation is completed. Go to
section §5.
SETTING 3: AUTOMATICALLY SETTING THE DOWN & UP END LIMITS (PRODUCT WITH BOTTOM
LOCK SYSTEM PROHIBITED):
1- Press simultaneously on the « UP » and « DOWN » buttons : the motor jogs.
2- Press the « DOWN » button > 2 s : the product runs down untill the down end limit detection. The product
moves briefly UP and returns to its down end limit. This indicates the limit is set correctly.
If the lower end limit does not set automatically after several attempts: Cut the power supply (2 seconds
minimum), repeat the operation 4.1, and then use the setting 2.
3 - Press 2 s on the "STOP" button to confirm the settings, the motor jogs. The operation is completed. Go to
section §5.
EN
4/12
1
+
> 2 s
1
2 3
2 3
2 s
> 2 s
4
2 s
