Attention:
screw the ground ring
terminal
(10)
to the throttle body,
hence avoiding any malfunctioning
of the system (Fig. 6).
Art. 5514747 - 5514749 -
5514750 - 5515720 - 5515785 -
5515786 - 5516341B
• Locate the Lambda sensor
and follow its cable until you reach
its connector (12).
• Disconnect the connector and
insert, into the circuit, the O2
controller (Fig. 7).
NB: Position the lambda emulator
taking care that the wires will not be
damaged by vibrations or heat.
Art. 5516458
(Fig. 8 - Fig. 9)
• Locate the lambda sensor
the vehicle head
• Follow the lambda cable until you
reach its connector
• Disconnect the connector and
insert, into the circuit, the O2
controller
• Disconnect the injector connector
(15) (Fig. 9)
• Apply the splice, supplied in the
Malossi kit, to the white/black wire
that exits the connector on the
injector
• Connect the red wire
comes from the CDI to the
electrical tap connector
(Fig. 9)
Warning:
once the faston is
connected to the electrical tap
connector we suggest to tape the
(Fig. 7)
(11)
(13)
on
(Fig. 8)
(14)
(18)
which
(16)
wire bunch, to avoid electrical tap
vibrations damaging the wires.
• Please connect the eyelet to the
ground node
crankcase (Fig. 8).
Art. 5517530B
- Fig. 12)
• Locate the lambda sensor
the vehicle exhaust piper
• Follow the lambda cable until you
reach its connector
• Disconnect the connector and
insert, into the circuit, the O2
controller
(21)
7
(17)
located on the
(Fig. 10 - Fig. 11
(10)
on
(Fig. 10)
(20) (Fig. 11)
(Fig. 12).
