Ausgangsstrom..................................................................................................................... ≤ 5 mA
Max Spannung....................................................................................................................... ≤ 30 V
Ausgangswiderstand Optokoppler RM+ / M- :
Tastverhältnis 0 % ................................................................ >100 kΩ (120 °C), > 10 MΩ (25 °C)
Tastverhältnis 100 % .............................................................. < 200 Ω (120 °C), < 100 Ω (25 °C)
Funktions- und Geräteeigenschaften
Automatischer Selbsttest (Optokoppler schalten nicht) ....................... zur Gerätefehlererfassung
Selbsttest, automatisch aktiviert...............................nach dem Einschalten und alle fünf Minuten
Anschlussfehler E-KE .....................................................ständig überwacht, Erfassungszeit < 20 s
Erfasster Gerätefehler während des Selbsttests.......Ausgang Status von (OK+, OK-) hochohmig,
................................................................................................... Tastverhältnis von M+/ M- = 0 %
Umgebungsbedingungen / EMV
EMV.................................................................................................................................... IEC 61326
Permanente Umgebungstemperatur.....................................................................- 46 °C...105 °C
Hohe Umgebungstemperatur (3h)........................................................................ 105 °C...125 °C
Schwingungen:
100 Hz ........................................................................................................................0,00797 g
200 Hz .......................................................................................................................0,17157 g
300 Hz .......................................................................................................................0,54279 g
650 Hz .......................................................................................................................0,00965 g
1000 Hz.....................................................................................................................0,02080 g
.......................................................................................................................................24 h je Achse
Schock ................................................................ 43 g, 1/2 Sinus, 11 ms, fünfmal in jeder Richtung
Anschluss
Steckverbindungen (IR155-1) ...........................................................................Samtec Micro Mate
.......................................................1 x TFML-110-02-S-D-LC (A+, A-, M+, M-, OK+, OK-, E, KE)
....................................................................................................2 x TFML-105-02-S-D-LC (L+, L-)
Schraubklemmen (IR155-2) ................................................................................... Phoenix Contact
.......................................................................... 1 x MKDS 3/8 (A+, A-, M+, M-, OK+, OK-, E, KE)
........................................................................................................................2 x MKDS 3/2 (L+, L-)
Allgemeine Daten
Betriebsart / Einbaulage...............................................................................Dauerbetrieb / beliebig
PCB Abmessungen (L x B x H) (IR155-1)..............................................113 mm x 50 mm x 15 mm
PCB Abmessungen (L x B x H) (IR155-2)...........................................125 mm x 60 mm x 19,5 mm
Gehäuse.......................................................................................................................................ohne
Befestigung.................................................................. Schraubbefestigung (Kunststoffschrauben)
Bei der Befestigung des Gerätes ist auf eine ausreichende Isolierung gegenüber dem Fahrzeug
bzw. den Befestigungspunkten zu achten.
Beschichtung ........................................................................................................................ Certonal
Software-Version ............................................................................................................. D329 V1.0
Gewicht............................................................................................................................. 50 ± 10 g
Werkseinstellung
Messverfahren (JP1: offen).......................................................................................................... DCP
Bestellangaben
Typ
Nennspg.
IR155-1
DC 0...800 V
IR155-2
DC 0...800 V
TBP106023deen / 09.2009
Versorgungsspg.
Art.-Nr.
DC 9...18 V
B9106 8133
DC 9...18 V
B9106 8134
Output current ...................................................................................................................... ≤ 5 mA
Max. voltage .......................................................................................................................... ≤ 30 V
Output resistance optocoupler RM+ / M- :
Duty cycle 0 % ...................................................................... >100 kΩ (120 °C), > 10 MΩ (25 °C)
Duty cycle 100 % .................................................................... < 200 Ω (120 °C), < 100 Ω (25 °C)
Functional and device characteristics
Automatic self test (optocouplers do not switch).................................. for detecting device errors
Self test, automatically activated.............................................after power on and every 5 minutes
Connection fault E-KE ...........................................continuously monitored, detecting time < 20 s
Detected device error during the self test................. output status of (OK+, OK-) high-resistance
............................................................................................................Duty cycle of M+/ M- = 0 %
Environmental conditions / EMC
EMC.................................................................................................................................... IEC 61326
Continuous ambient temperature .........................................................................- 46 °C...105 °C
High ambient temperature (3h) ............................................................................ 105 °C...125 °C
Vibrations:
2
/ Hz
100 Hz........................................................................................................................0.00797 g
2
/ Hz
200 Hz.......................................................................................................................0.17157 g
2
/ Hz
300 Hz.......................................................................................................................0.54279 g
2
/ Hz
650 Hz.......................................................................................................................0.00965 g
2
/ Hz
1000 Hz.....................................................................................................................0.02080 g
.................................................................................................................................24 h in each axis
Shock...................................................................43 g, 1/2 sine, 11 ms, five times in each direction
Connection
Connectors (IR155-1)......................................................................................... Samtec Micro Mate
......................................................1 x TFML-110-02-S-D-LC (A+, A-, M+, M-, OK+, OK-, E, KE)
...................................................................................................2 x TFML-105-02-S-D-LC (L+, L-)
Screw-type terminals (IR155-2)..............................................................................Phoenix Contact
..........................................................................1 x MKDS 3/8 (A+, A-, M+, M-, OK+, OK-, E, KE)
.......................................................................................................................2 x MKDS 3/2 (L+, L-)
General data
Operating mode / mounting................................................... continuous operation / any position
PCB dimensions (L x W x H) (IR155-1).................................................113 mm x 50 mm x 15 mm
PCB dimensions (L x W x H) (IR155-2)..............................................125 mm x 60 mm x 19.5 mm
Enclosure .............................................................................................................................. without
Mounting method.........................................................................screw mounting (plastic screws)
When installing the device, ensure sufficient insulation between the device and the vehicle resp.
the mounting points.
Coating.................................................................................................................................. Certonal
Software version .............................................................................................................. D329 V1.0
Weight .............................................................................................................................. 50 ± 10 g
Factory setting
Measurement method (JP1: open)..............................................................................................DCP
Ordering information
Typ
Nominal volt.
IR155-1
DC 0...800 V
IR155-2
DC 0...800 V
A-ISOMETER® iso-F1 (IR155)
Supply volt.
Art. No.
DC 9...18 V
B9106 8133
DC 9...18 V
B9106 8134
2
/ Hz
2
/ Hz
2
/ Hz
2
/ Hz
2
/ Hz
7
