DNC90
DATI TECNICI • TECHNICAL DATA • TECHNISCHE MERKMALE
Portata nominale (max)
Nominal flow (max)
Nominaler Durchfluß (max)
Pressione massima
Maximum pressure
Maximaler Betriebsdruck
Contropressione massima allo scarico
Maximum tank pressure
Maximaler Gegendruck Tankleitung
Massima trafila interna
Maximum internal leakage
Maximale interne Leckage
Temperatura d'utilizzo
Temperature range
Betriebstemperatur
Viscosità olio
Oil viscosity
Ölviskosität
Fluido
Fluid
Öl
FILETTATURA • THREAD • GEWINDE
CODICE TIPO
COPPIA DI SERRAGGIO Nm
MODEL TYPE
BEZEICHNUNG GEWINDE
N M 22 X 1,5
B 1/2 Gas
R 7/8" UNF-14
40 (1.576")
52 (2.5")
B
P1
P
A
DC008_72
DISTRIBUTORI COMPONIBILI
MODULAR DIRECTIONAL CONTROL VALVES
KOMBI-STEUERGERÄTE
90 (100) l/min
23.7 (26.3) gpm
250 (3646)
bar (psi)
50 (730)
bar (psi)
8 cc/min
(21 cSt - 100 bar)
-20°C +80°C NBR seals
-20°C +130°C HNBR seals
Da 10 cSt a 100 cSt
From 10 cSt to 100 cSt
Von 10 cSt nach 100 cSt
Olio a base minerale
Mineral based oil
Mineral Öl
T - T1
TORQUE Nm
TYPE
ANZUGSMOMENT Nm
GEWINDE
80
M 27 X 2
70 3/4 Gas
80 1"1/16 UNF-12
L 40 (1.576")
42 (1.65") 52 (2.5")
B
T1
A
DIMENSIONI • SIZE • ABMESSUNGEN
MOD.
L
MOD.
mm (inch)
MOD.
DNC90/1 104 (4.1)
DNC90/2 146 (5.75)
DNC90/3 188 (7.4)
DNC90/4 230 9.05)
DNC90/5 272 (10.7)
P
180
Parallel Circuit DNC90/2 BZ A1X2 PTT1
TIPO
P
180
Tandem Circuit DNC90/2 BZ A1PRX2 PTT1
T
11.5 (0.45")
MOD.
MASSA Kg (lb)
WEIGHT Kg (lb)
MOD.
mm (inch)
GEWICHT Kg (lb)
MOD.
8.3 (18.30) DNC90/6 314 (12.36)
11 (24.25) DNC90/7 356 (14)
14 (30.86) DNC90/8 398 (15.6)
17 (37.48)
20 (44.09)
B
P1 B A A
T
T1
Power beyond
B A
P1 B A
T
T1
Power beyond
113.5 (4.5")
55 (2")
13.5 (0.53")
L MASSA Kg (lb)
WEIGHT Kg (lb)
GEWICHT Kg (lb)
23 (50.71)
26 (57.32)
29 (63.93)
C.O.
T
Carry over
C.O.
T
Carry over
