Bondioli & Pavesi QH008 Bedienungsanleitung Seite 397

A20
45
TERMOSTATO
THERMOSTAT
THERMOSTATE
OIL IN
Perdita di carico - A20 (Temp.olio = 80 °C)
bar
Pressure drop - A20 (Oil temp. = 80 °C)
Druckgefälle - A20 (Öl temp. = 80 °C)
1,6
V = 68 cSt
1,4
V = 46 cSt
1,2
V = 32 cSt
1,0
0,8
0,6
0,4
0,2
0,0
0 25 50 75
Portata olio (l/min)
Oil flow (l/min)
Öldurchfluß (l/min)
CODICE
CODE
BEST.-NR.
FR634030011 SCM A20 IA PRED. GR1
FR634030012 SCM A20 IS PRED. GR1
FR634030013 SCM A20 IA MOT. IDR. GR1
FR634030014 SCM A20 IS MOT. IDR. GR1
HY004_6
SCAMBIATORI DI CALORE IN ALLUMINIO
ALUMINIUM HEAT EXCHANGERS
ALUMINIUM WÄRMETAUSCHER
340 ± 2
250 45
150
N° 4 ø 11
206 ± 2
X
Potenza termica - (kW)
kW
Heatxchange (Thermal) capacity - (kW)
Kühleistung - (kW)
6
Wo = 125 l/min
5,5
Wo = 50 l/min
5
Wo = 25 l/min
4,5
4
3,5
3
2,5
2
100 125 1,5
20
Differenza di temperatura (°C)
Temperature difference (°C)
Temperaturdifferenz (°C)
TIPO DIAMETRO VENTOLA
TYPE FAN DIAMETER
TYP
LÜFTERSDURCHMESSER
X
OIL OUT
M22X1.5
N°2
3/4"G BSP
9
OPZIONE PIEDE
FEET OPTIONS
FUSS-OPTION
30 40 50
CILINDRATA MOTORE
DISPLACEMENT MOTORS
FÖRDERVOLUMEN MOTOR
3
mm cm /h
220
220
220 6
220 6
L MAX
45 40 70
3
ASPIRATING TYPE
125
155
CODICE
CODE
BEST. - NR.
SI FR290000020 PIEDINO DX
SI FR290000019 PIEDINO SX
Perdita di carico - A20 (Visc. = 46 cSt)
bar
Pressure drop - A20 (Visc. = 46 cSt)
Druckgefälle - A20 (Visc. = 46 cSt)
6,0
To = 40 °C
5,0
To = 60 °C
To = 80 °C
4,0
3,0
2,0
1,0
0,0
0 25 50 75
Portata olio (l/min)
Oil flow (l/min)
Öldurchfluß (l/min)
MASSA
WEIGHT
L MAX
GEWICHT
mm
Kg
195 6
195 6
255 7
255 7
SOFFIANTE
BLOWER TYPE
GEBLÄSE
ASPIRANTE
ANSAUGUNG
TIPO
TYPE
TYP
100 125
CAPACITA'
CAPACITY
KAPAZITÄT
lt
1,45
1,45
1,45
1,45
