Appendix

Optional Accessories

Probe tips for gauges
M2.5
1/8"
Ø4.5
(.18 dia.)
Fig. 6 Standard probe tip type 2
Standard probe tip type 2
Option probe tip type 2
Option probe tip type 2
Option probe tip type 2
induSENSOR, Series LVDT, Gauge
M2.5
Ø4.8
(.20 dia.)
Fig. 7 Option type 10
Steel
Hard metal Option probe tip type 10
Plastics Option probe tip type 11
Ruby Option probe tip type 13
M2.5
Ø10
(.39 dia.)
Fig. 8 Option type 11
Steel Dimensions in mm (inches), not to scale
Steel
Steel
Ø4.5
(.18 dia.)
M2.5
45 °
Fig. 9 Option type 13
Page 37
