Sensor Mounting - MICRO-EPSILON induSENSOR DTA-1G8 Betriebsanleitung

Installation and Assembly
4.2
This offers the highest reliability because the gauge is clamped flatly on its cylindrical housing.
Do not clamp the
The integrated spring presses the probe tip of the gauges against the measuring object.
gauge with a grub
screw at one point. Avoid lateral forces on the probe tip.
Damage to the
gauge.
Fig. 3 Mounting of gauges with circumferential clamping using the optional MBS12/8 mounting block
1) Mounting using MBS12/8 mounting block or other accessories, see appendix.
induSENSOR, Series LVDT, Gauge

Sensor Mounting

Use circumferential clamping on the housing (gauges) to mount the sensor.
Connect the gauge to the controller using plug connectors or, depending on the variant, wire
see 4.6.
Readjust the controller when replacing the gauge.
Mounting block
Clamping shaft
Adapter ring
Mounting area
terminals,
