Functional Principle, Technical Data

2.3 Technical Data
Model
Measuring range
Linearity
Repeatability
1
Temperature stability
Sensitivity
Excitation frequency
Excitation voltage
Connection
Storage
Temperature range
Operation
Pressure resistance
Shock (DIN EN 60068-2-27)
Vibration (DIN EN 60068-2-6)
Protection class (DIN EN 60529)
Material
Weight
SMR
Typical spring forces MMR
2
EMR
Compatibility
Typ. service life
FSO = Full Scale Output SMR = Start of measuring range, MMR = Mid of measuring range, EMR = End of measuring range
1) Averaging over 100 values; 200 repetitions
2) Removing the bellows changes the spring forces
induSENSOR, Series LVDT, Gauge
DTA-1G8 DTA-3G8
±1 mm ±3 mm
≤ ±3 µm ≤ ±9 µm
≤ 0.15 µm ≤ 0.45 µm
133 mV / mm/V 85 mV / mm/V53 mV / mm/V44 mV / mm/V 133 mV / mm/V 85 mV / mm/V53 mV / mm/V 44 mV / mm/V
5 kHz 5 kHz
Integrated cable 3 m with open ends; axial cable outlet; drag-chain suitable;
cable diameter 3.1 mm; min. bending radii: fixed installation 25 mm, moving 38 mm, drag chain 47 mm
-20 ... +80 °C (-4 ... +176 °F) (without bellows); 0 ... +80 °C (+32 ... +176 °F) (with bellows)
Stainless steel (housing); FPM (bellows); PUR (cable sheath); PVC/PP (cable braids)
approx. 70 g approx. 70 g approx. 75 g approx. 85 g
1.3 N 0.8 N
1.55 N 1.5 N
2 N 2.5 N
DTA-5G8 DTA-10G8 DTA-1G8-V DTA-3G8-V DTA-5G8-V DTA-10G8-V
±5 mm ±10 mm
≤ ±15 µm ≤ ±30 µm ≤ ±3 µm
≤ ±0.3 % FSO
≤ 0.75 µm ≤ 1.5 µm
≤ 250 ppm FSO / K
5 kHz 2 kHz
550 mV
-40 ... +80 °C (-40 ... +176 °F)
Atmospheric pressure
40 g / 6 ms in 3 axes, 1000 shocks each
±1.5 mm / 10 ... 58 Hz in 2 axes, 10 cycles each
±20 g / 58 ... 500 Hz in 2 axes, 10 cycles each
IP65 (with bellows); IP54 (without bellows)
approx. 70 g
1 N 0.7 N
1.9 N 1.9 N
3 N 3.5 N
MSC7401, MSC7802, MSC7602
5 million cycles
±1 mm ±3 mm ±5 mm
≤ ±9 µm ≤ ±15 µm
0.15 µm ≤ 0.45 µm ≤ 0.75 µm
5 kHz 5 kHz
approx. 70 g approx. 80 g approx. 85 g
depending on air pressure
±10 mm
≤ ±30 µm
≤ 1.5 µm
5 kHz 2 kHz
Page 28
