Installation

Safety

• Only an accredited electrician is allowed to perform the installation described in this document.
• Read and obey the instructions in this document before installation and operation of the product.
• Installation must fulfil local safety regulations and ensure the IP classification if the box is modified.
• Make sure that the cables in the CGC500™ are not loose due to vibrations during transport. If any
cables are loose, reconnect the wires and tighten the screws.
• Use safety shoes during installation.

Tools

Recommended tools for installation:
• Screwdriver
• Stripping pliers
• Spirit level
• Drill
• Ethernet cable

Other necessary equipment

The following parts are also needed to install the entire grid controlling network. These are purchased sep-
arately.
• CHARGESTORM CONNECTED® (or other CTEK charging stations compatible with the CGC500™)
• Ethernet switch
• Ethernet cables
• Screw joints for cable feeds
• Screws for wall mounting

General information before installation

To install the network cables

You will need one cable between each charging station and switch. For instance, if there are eight charging
stations in the installation, you will need eight cables.
1. Install one cable between the load monitor and the switch.
2. If Internet access is required, install an appropriate cable.
Note: The Ethernet cables must not be longer than approx. 90 m. If longer cables are needed, repeaters
must be used to strengthen the signal. The Ethernet cables must be Cat5 or Cat6 cables with an RJ45
connector at each end.
CTEK SWEDEN AB 5
