B22 MIDDLE PEDAL SUPPORTING
ROD
B23 NUT M8
B24 BUSH Φ8x(Φ12+Φ15)
B25 BEARING 6001 (TPX)
B27 SCREW M8x45
B30 SCREW M12x133
B31 BUSH Φ15xΦ12.35x90mm
B32 BEARING 6003zz
B33 BUSH
B34 PEDAL HOUSING ( R )
B35 PEDAL HOUSING ( L )
B36 SCREW
B37 PEDAL REINFORCEMENT STRIP
B38 SCREW
C1 SIDE CONNECTING TUBE ( L )
C2 SIDE CONNECTING TUBE ( R )
C3 END CAP
C4 ADJUSTED NUT
C5 ADJUSTED END Φ50
D CONSOLE SUPPORTING TUBE
D1 SENSOR WIRE 350mm
D2 SENSOR WIRE 200mm
R1 SIDE TUBE COVER SET (R1)
R2 SIDE TUBE COVER SET (R2)
R3 SIDE TUBE COVER SET (R3)
R4 SIDE TUBE COVER SET (R4)
M1 BUSH
M2 CLIP R32
M3 MOTOR
36
2 G CONSOLE
4 G1 CONSOLE SCREW M5x10
1 G2 STRIDE LED SENSOR BOARD
4 H WATER BOTTLE HOLDER
4 J1 SCREW M10x16
2 J2 SCREW M4x16
2 J3 SCREW M4x6
16 J4 SCREW M8x55
2 J5 WASHER M8x18
2 J6 SCREW M8x20
2 J7 SCREW M12x73
4 J8 WASHER M12x20
4 J9 NUT M12
8 J10 SCREW M12x109
1 J11 HANDLE BAR SCREW
1 J12 HANDLE BAR SCREW
2 J13 SCREW M8x16
2 J14 WATER BOTTLE HOLDER
SCREW
2 L1 SIDE TUBE COVER SET (L1)
1 L2 SIDE TUBE COVER SET (L2)
1 L3 SIDE TUBE COVER SET (L3)
1 L4 SIDE TUBE COVER SET (L4)
1 M4 SCREW
1 N1 BUSH Φ12.05*17*21.2mm
1 N2 CLIP (R40)
1 N3 BEARING 2203(MRB)
6 N4 SPACER RING (L)
8 N5 SPACER RING (R)
2 N6 SCREW
1
4
1
1
4
6
2
4
4
2
6
18
18
4
6
6
4
2
1
1
1
1
2
4
2
2
4
4
8
