CARDIOSTRONG EX90 Plus Montage- Und Bedienungsanleitung Seite 34

A27 POWER CORD SOCKET
A28 SCREW M3x10
A29 SCREW M8x10
A30 TRANSPORTATION WHEEL
A31 SCREW M12x53
A32 PRESSING PIPE
A33 WASHER Φ10xΦ23x2T
A34 BEARING 6200 (MRB)
A35 SCREW M10x30
A36 JSHAPE SCREW M6
A37 WIRE (AC POWER SWITCH TO
POWER CORD)
A38 WASHER M6x Φ16xΦ29.2x2T
A39 GROUND WIRE
A40 POWER CORD
A41 FLYWHEEL Φ327
A42 NUT3/8"
A43 TENSION CABLE 400mm
A44 SCREW M5x10
A45 TURING PLATE
A46 CRANK
A47 BEARING NUT
A47- BUSH Φ25.2xΦ29.2x54.5mm
1
A47- BUSH Φ25.2xΦ29.2x5mm
2
A48 SCREW M8x25
A105 SMALL CHAIN COVER ( R )
A106 MAIN CHAIN COVER ( R )
A107 SCREW M4x12
34
1 A77 FLAT KEY 7x7x20mm
2 A80 FRONT PEDAL SUPPORTING
TUBE
2 A81 WASHER M10xΦ27x2T
2 A82 SCREW M10x40mm
4 A83 NUT
1 A84 BRAKE
2 A85 SPRING
2 A87 AXLE FOR MOTOR PUSH ROD
1 A88 NUT
1 A89 NYLON SLEEVE
1 A90 PUSH ROD BRACKET (FRONT)
1 A91 END CAP
1 A93 PUSH ROD BRACKET (REAR)
1 A94 SCREW M8x20
1 A95 SCREW 5/32"x3/4" (M4x19mm) 12
2 A96 NUT M6
1 A97 SIDE DECORATION HOUSING
SET ( L )
4 A98 SIDE DECORATION HOUSING
SET ( R )
2 A99 FRONTSIDE DECORATION
COVER
2 A100 SCREW M4x20
1 A101 END CAP
1 A102 SMALL CHAIN COVER ( L )
1 A103 MAIN CHAIN COVER ( L )
4 A104 UPPER DECORATION HOUSING
1 D3 SENSOR WIRE 300mm
1 D4 HANDLE PULSE WIRE
8 D5 HANDLE PULSE RING
Φ31.8x0.9Tx19.5mm
2
2
2
2
4
1
1
2
2
8
2
1
2
8
2
2
2
2
10
4
1
1
1
1
2
2
EX90 PLUS
