1. DEVICE OVERVIEW

16
15
14
13
12
11
10
1
Lock
2
Terminal resistor
3
Connector
4 Speaker
5 Door opener button
6 Door opener indication led (blue)
7
Ambient lighting
EN
17 18 19
9 8 7 6 5
8
9
10
11
12
13
14
20
Call indication LED (green)
Talk button
Light switch button
Function button
Volume button
Ringtone mute indication LED (red)
Do not disturb button
TOP
15
Microphone
16
3.5'' display
17
Brightness touch button
18 Contrast touch button
19 Colour control touch button
20 Select image touch button
10-577
1
2
3
4
