Cfast - Siemens SIMATIC IPC477E PRO Betriebsanleitung

9.5.1.2

CFast

Pin
S1
S2
S3
S4
S5
S6
S7
PC1
PC2
PC3
PC4
PC5
PC6
PC7
PC8
PC9
PC10
PC11
PC12
PC13
PC14
PC15
PC16
PC17
SIMATIC IPC477E PRO
Betriebsanleitung, 11/2020, A5E39912461-AD
Kurzbezeichnung Bedeutung
SGND Signal GND (ground for signal integrity)
A+ SATA Differential
A- SATA Differential
SGND Signal GND (ground for signal integrity)
B- SATA Differential
B+ SATA Differential
SGND Signal GND (ground for signal integrity)
CDI Card Detect In
GND Device GND
TBD TBD (not connected)
TBD TBD (not connected)
TBD TBD (not connected)
TBD TBD (not connected)
GND Device GND
LED1 LED Output (not connected)
LED2 LED Output (not connected)
IO1 Reserved Input/Output (not connected)
IO2 Reserved Input/Output (not connected)
IO3 Reserved Input/Output (not connected)
PWR Device Power (3.3V)
PWR Device Power (3.3V)
GND Device GND
GND Device GND
CDO Card Detect Out
Technische Angaben
9.5 Hardwarebeschreibungen
131
