Gazelle Makki Benutzerhandbuch Seite 114

28
Adjusting the stem:
Depending on your model, the Makki is fitted with handlebar
tube A or handlebar tube B.
1. Loosen socket screw below the stem
E
using Allen key 5.
2. Loosen socket screw between the handlebar tube
F
and the stem using Allen key 5.
6
3. Turn the stem upwards or forwards.
6
4. Adjust the handlebars such that your arms are approxi-
7
mately 90 degrees relative to your upper body.
Ensure that you have a posture whereby your shoulders
and arms are relaxed.
5. Afterwards, firmly tighten the socket screw
(for torque see section 11.1.1, page 87).
" " When adjusting the handlebar ensure
DANGER
that the handlebar can move all the way to the
right and left without putting the cables under
strain.
Makki
Handlebar tube A
by a few turns
6
5
of the stem
F
Handlebar tube B
6
5
6
E
5
Fixed
E
Loose
Fixed
7
F
Loose
7
