Cleaning and Maintenance
07
To park it without using the stand:
- Position the bicycle on a flat, stable surface.
- Lean the rear wheel or saddle against a stable
object.
- Rotate the handlebars so that they are facing in
the direction in which the bicycle is leaning.
- Ensure that the bicycle is stationary and stable.
If it seems that the bicycle may fall over, posi-
tion it elsewhere and/or in another manner.
5. UNSCHEDULED
MAINTENANCE OPERATIONS
5.a - Removing and remounting the
wheels units
- It is necessary to remove the wheel units when
repairing tyres or other wheel components.
It may also be useful when transporting the bi-
cycle (for example: in the boot of your car).
It is absolutely essential to de-
flate the tyres when transporting
the bicycle in a car or any other
motor vehicle!
5.b - Removing the front wheel
- Pull the eccentric lever so that it moves away
from the wheel hub. The lever can be rotated
by approx. 180° around its axis (fig. "64").
- Push the lever towards the hub to "hook it" to
the ring groove (fig. "65").
- Rotate the eccentric lever in order to unscrew
the axle pin and extract it from the wheel hub
(fig. "66").
- Remove the complete wheel from the fork
(fig. "67").
EN_32
- Insert the transport block (f - supplied) be-
tween the brake pistons (fig. "68").
Never operate the hydraulic brakes when the
wheel unit has been removed. Use the trans-
port blocks (f - supplied) and remember to re-
move them before replacing the front wheel.
Take care no to lose the two spacers (d) (fig.
"69").
5.c - Mounting the front wheel
Make sure that the two spacers (d) are in po-
sition.
- Remove the transport block (f) from the brake
pistons (fig. "70").
Do not operate the front brake lever.
- Insert the wheel in the fork, making sure that
the brake disk is positioned between the brake
pistons.
- Insert the axle pin from the brake opposite side
and push it until it protrudes from the other
end of the wheel hub (fig. "71").
- Push the lever towards the hub to "hook it" to
the ring groove (fig. "65").
- Turn the eccentric lever until hooking the pin
(by hand) (fig. "72").
- Raise the lever and push it until comes to rest
against the fork (fig. "73").
- Check that the wheel has been mounted se-
curely and correctly.
