– The adaptor supplied with this appliance is intended for this appliance only, do not use
it for other purposes. Also, use only the supplied adaptor with this appliance, do not use
any other adaptor for charging (e.g. from another appliance).
– The power cord must not be damaged with sharp or hot objects, open fire, it must not be
sunk into water or bent over sharp edges.
For trouble-free operation of the vacuum cleaner, please use the
tested micro-filters recommended by the producer.
II. EQUIPMENT AND ACCESSORIES (Fig. 1)
A – vacuum cleaner
A1 – ON/OFF switch
A2 – operation signal lights and charging
lights
A3 – container lock button
A4 – charging port
A5 – handle
B – dust container
B1 – fabric input filter
B2 – separator
B3 – input filter
C – accessories
C1 – crevice nozzle
C2 – brush
D – extension adapter
D1 – ON/OFF switch + suction power
control
D2 – foldable part with handle
D3 – foldable part lock button
D4 – vacuum cleaner lid lock button
D5 – depression for attachment of accessories
III. VACUUM CLEANER PREPARATION
Remove all packing material, take out the vacuum cleaner and the accessories. Remove all
possible adhesion foils, stick-on labels or paper from the appliance.
VACUUM CLEANER ASSEMBLY
When assembling the vacuum cleaner, follow the procedure indicated in Fig. 1. Select
appropriate accessories (Fig. 6) depending on the required use (hand vacuum cleaner / stick
vacuum cleaner). For disassembly, proceed the other way round and release the locks.
E – floor nozzle with rotation brush
E1 – floor nozzle lock button
E2 – removable brush
E3 – brush lock
E4 – LEDs illuminating the space in front of
the vacuum cleaner
E5 – śide brushes
F – mop attachment
F1 – mopping textile
F2 – rubber plug (filling orifice)
F3 – damping switch
G – adapter
H – plastic wall bracket
I – screw
J – wall plug
K – filling cup
