Clatronic km 2961 profi cook Bedienungsanleitung Seite 26

1. Cut the food to be mixed into small pieces.
2. Transfer the ingredients to the carafe and put the lid in
position. The lid must be positioned fi rmly.
Do not overfi ll! Do not exceed the maximum quantity
of 1100 ml stated on the mixing bowl!
3. Connect the mains lead to a properly installed 230 V,
50 Hz safety power socket.
4. Switch the device on (Level 1 or 2 etc) or use pulse
operation (P). The carafe must be held tightly during
mixing.
• For constant mixing (continuous mode):
The rotating speed can be continuously adjusted from
1 to 9:
Level 1 = low rpm
Level 9 = high rpm
Shift the selector to „0" to switch off the appliance.
• For pulse mode (mixing at brief intervals):
shift the switch to „0" position. The switch snaps
into place. The appliance is off now. Turn the
switch now to position „P". The switch must be
kept in this position for the desired interval. When
the switch is released, it returns automatically to
„0" position.
In order to insert more food to be mixed the small
lid may be removed. Please switch off the machine
before doing so.
5. Shift the selector to „0" to switch off the appliance.
6. In order to remove the mixer jug turn it counterclock-
wise.
Clean the used parts as described in „Cleaning".
Chopping up Ice Cubes
The blade in the mixing vessel is also suitable for chop-
ping up ice cubes. Please only fi ll the carafe up to 2/3
full with ice cubes. Only use pulse operation (P) for the
chopping process.
Operating the Food Processor Bowl
1. Press the button (3) and fold up the drive arm. Please
ensure that the mixing bowl has been removed and
replaced by the safety cover.
2. Place the drive of the food processor bowl on the
drive axle on the base.
3. Mount the tool you wish to use by inserting the upper
end into the opening provided on the arm (Pay attenti-
on to the corresponding coloured markings.).
4. Now fi ll in your ingredients.
5. Do not overfi ll the machine; the maximum quantity of
ingredients is 1.2 kg.
6. Lower the drive arm until it locks in place.
7. Insert the mains plug into a properly installed 230V /
50 Hz safety power socket.
8. Switch the machine using the level regulator to a
speed between 1 and 9 (corresponding to the mixtu-
re).
26
6....-05-KM 2961 PC_Inox A5 26
Always choose a utensil and a speed according to the
following table:
Product/Type of Max.
Preparation Quantity
Heavy mixtures
(e.g. bread dough 1 kg
or short pastry)
Light mixtures
(e.g. sponge 1,2 kg
mixture)
Sponge mixture
1 l
or wafer mixture
Cream min 250 ml
Whipped egg 4-6 egg
whites whites
Mayonnaise min. 500 ml
Liquids, shakes up to 1,1 l
Remarks
• With heavy mixtures, do not operate the machine
for more than ten minutes, and then allow it to
cool down for a further ten minutes.
• Depending on its constituency it may be necessa-
ry to remove the mixture from the sides of the mi-
xing bowl and return it to the mixing mechanism.
To do so, switch the mixer off and use the spatula.
9. After kneading/stirring turn the switch (2) back to the
„0" position as soon as the mixture has formed a ball.
Then remove the mains plug.
10. Press the button (3) and pull the arm upwards.
11. The inserted tool can be removed by pressing the
eject button.
12. The mixture can now be released with the help of a
spatula and removed from the mixing bowl.
Clean the parts as described under „Cleaning".
Cleaning
General
• Remove the plug from the socket before cleaning!
• Accessories: None of the accessories is suitable for
cleaning in the dishwasher.
• Clean the bowl and the mixing vessel carefully imme-
diately after each procedure. To do so, remove the
bowl in order to be able to clean off any residues on
the drive shaft.
• Never use sharp objects for cleaning!
• Never use abrasive detergents!
• Use a moist towel to clean the outside of the basis
appliance.
• In the case of intensely colored foodstuffs (e.g. car-
rots), the plastic parts can be stained: clean them with
oil.
Food Processor Bowl
• Any removable parts which have come into contact
with food (utensil and bowls) can be cleaned in soapy
water.
Mixing Bowl
• Fill half of the jug with water and press the push
button for approximately 10 seconds. Then pour out
the liquid.
• Remove the mains plug from the socket.
Max. Opera-
Utensil Level
ting Time
1-2 First min.
Dough hook
4-5 2 to 9 min.
Beater 4-5 8 to 10 min.
Beater 1-5 5 to 10 min.
Whisk -9 up to 5 min.
Whisk -9 up to 5 min.
Whisk -9 up to 5 min.
Mixer vessel 4-5 max. 1 min.
