1. Introduction

Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
We hope you have a lot of fun and success using your
new machine.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by
the product that occurs due to:
• improper handling,
• noncompliance of the operating instructions,
• repairs by third parties, not by authorized service
technicians,
• installation and replacement of non-original spare
parts,
• non-intended use,
• Failure of the electrical system in the event of the
electrical regulations and VDE provisions 0100,
DIN 571 13 / VDE 01 13 not being observed.
We recommend:
That you read through the entire operating instruc-
tions before putting the machine into operation.
These operating instructions are to assist you in get-
ting to know your machine and utilize its proper ap-
plications.
The operating instructions contain important notes on
how you work with the machine safely, expertly, and
economically, and how you can avoid hazards, save
repair costs, reduce downtime and increase the relia-
bility and service life of the machine.
In addition to the safety requirements contained in
these operating instructions, you must be careful to
observe your country's applicable regulations.
The operating instructions must always be near the
machine. Put them in a plastic folder to protect them
from dirt and humidity. They must be read by every
operator before beginning work and observed con-
scientiously. Only persons who have been trained in
the use of the machine and have been informed of
the various dangers may work with the machine. The
required minimum age must be observed.
In addition to the safety requirements in these oper-
ating instructions and your country's applicable regu-
lations, you should observe the generally recognized
technical rules concerning the operation of identically
constructed devices.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
18 | GB
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58

2. Device description (Fig. 1 - 2)

1. Tank full indicator
2. Frame
3. Tank
4. Socket - 400V
5. Socket - 230V
6. Earthing screw
7. Transport handle
8. Battery
9. Overload switch (up = ON, down = OFF)
10. Voltmeter
11. Connection - 12V
12. Oil filler tube
13. Transport wheels
14. Motor switch
15. Air filter
16. Reversing starter
17. Motor
18. Fuel tap
19. Choke
20. Tank cap

3. Scope of delivery

A. Transport wheels
B. Support foot
C. Adapter - 400V
D. Adapter - 230V
E. Spark plug wrench
F. Hexagonal bolt (M6 x 12)
G. Hexagonal bolt (M8 x 20)
H. Hexagonal bolt (M8 x 40)
I. Wheel axle
J. Transport handles
K. Hexagonal nut (M12)
L. Hexagonal nut, self-locking (M8)
M. Locking nut (M6)
N. Locking nut (M6)
O. Spring washer (2x)
P. Washer (2x)
Q. Washer, plastic (4x)
R. Operating manual
S. Battery 14V / 17Ah

4. Intended use

The machine may only be used in the intended man-
ner. Any use beyond this is improper. The user/opera-
tor, not the manufacturer, is responsible for damages
or injuries of any type resulting from this.
An element of the intended use is also the observance
of the safety instructions, as well as the assembly in-
structions and operating information in the operating
manual. Persons who operate and maintain the ma-
chine must be familiar with the manual and must be
informed about potential dangers.
