4. To remove the spool brake hub, release the spool brake tightening knob in the brake center and pull the brake
halves apart.
To install a new wire spool:
1. Open the wire feeder top cover and the wire spool locking cover.
2. Attach the wire spool brake halves to the new wire spool by pushing them together inside the wire spool.
Secure them together by turning the tightening knob in the brake center.
Attach the spool brake hub to the wire spool so that the tightening knob is on the right, seen from the front.
3. Place the wire spool into its socket.
Ensure that the wire spool is facing the right direction, the filler wire running from the top of the spool to the feed rolls.
