4.3.1 Cabinet options
The cabinet can be delivered with a variety of options. Select
which items you need in your setup from the table below.
Product
Description
number
98839512 Sine-wave filter 3 - 5.6 A
99892974 Sine-wave filter 4.1 - 7.2 A
98839513 Sine-wave filter 5.6 - 10 A
98839514 Sine-wave filter 7.2 - 13 A
99892975 Sine-wave filter 10-16 A
98839515 Sine-wave filter 13-24 A
98839516 Sine-wave filter 16-32 A
99892976 Sine-wave filter 24 - 37.5 A
98839517 Sine-wave filter 32-44 A
98839518 Sine-wave filter 37.5 - 61 A
98839519 Sine-wave filter 44-73 A
98839520 Sine-wave filter 60-90 A
99892977 Sine-wave filter 73-106 A
98839521 Sine-wave filter 90-147 A
99892978 Sine-wave filter 106-177 A
98839497 Amp meter 40 A
98839498 Amp meter 100 A
98839499 Amp meter 150 A
98839500 Amp meter 250 A
98839511 Volt meter with phase switch
98839540 CUE emergency switch 4 - 5.6 A DOL
99894429 CUE emergency switch 6-10 A DOL
99894430 CUE emergency switch 9-13 A DOL
99894431 CUE emergency switch 13-16 A DOL
99894432 CUE emergency switch 17-23 A DOL
99894433 CUE emergency switch 24-32 A DOL
99894434 CUE emergency switch 30 - 37.5 A DOL
99894482 CUE emergency switch 37-44 A DOL
99894493 CUE emergency switch 48-61 A DOL
99894494 CUE emergency switch 63-73 A DOL
99894495 CUE emergency switch 60-90 A DOL
99894496 CUE emergency switch 90-106 A DOL
99894497 CUE emergency switch 105-147 A DOL
99894513 CUE emergency switch 132-177 A DOL
99894514 CUE emergency switch 4 - 5.6 A SD
99894515 CUE emergency switch 6 - 7.2 A SD
99894516 CUE emergency switch 7-10 A SD
98839541 CUE emergency switch 9-13 A SD
99894517 CUE emergency switch 13-16 A SD
98839542 CUE emergency switch 17-23 A SD
99894518 CUE emergency switch 24-32 A SD
98839543 CUE emergency switch 27.6 - 37.5 A SD
99894531 CUE emergency switch 39.7 - 44 A SD
99895266 CUE emergency switch 48-55 A SD
98839544 CUE emergency switch 51.8 - 61 A SD
99894532 CUE emergency switch 63.8 - 73 A SD
99895311 CUE emergency switch 64 - 86.2 A SD
98839545 CUE emergency switch 82.8 - 90 A SD
99894533 CUE emergency switch 90-106 A SD
98839546 CUE emergency switch 103.5 - 147 A SD
99894534 CUE emergency switch 138-177 A SD
98839493 Dry-running light
98839494 Fault Light and Reset alarm switch
98839495 Operating light
8
Product
Description
number
98839496 CUE display on front door
Panel light w service plug 230 V + RCBO 30 mA
98839531
10 A
98839533 CIU 150 Profibus DP
98839534 CIU 200 Modbus RTU
98839535 CIU 260 GSM EU
98839536 CIU 280 GRM EU
98839537 CIU 300 BACnet MS/TP
98839538 CIU 500 Ethernet
98843192 Control CUE Cabinet Heater 30 W
98839539 MCB 114 CUE extension board

4.4 Applications

The CUE series and Grundfos standard pumps are a supplement
to the Grundfos E-pumps range with integrated frequency
converter.
A CUE solution offers the same E-pump functionality in these
cases:
• In main voltages or power ranges which are not covered by
the E-pump range.
• In applications where an integrated frequency converter is not
permissible.
The cabinet range as option also includes the Grundfos Fieldbus
connectivity platform via CIU boxes which enables remote control
and monitoring of the CUE installation.
The cabinet range is designed to operate a single pump with an
asynchronous electrical motor. The frequency converter itself is
designed to work with Grundfos pumps of any given type.
